凯斯零件查询(8630) - CASE IH BALE WRAPPER (1/95-12/97) (2-32) - HYDRAULIC SYSTEM, 8630, MANUAL CONTROL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
277032A1
|
[1] |
VALVE
|
CAS
ASSY., control
|
| 1A. |
REF
|
[1] |
INSTRUCTION
|
NH
DECAL, See Figure: 2-92
|
| 2. |
277873A1
|
[2] |
CONTROL LEVER
|
CAS
|
| 3. |
814-8070
|
[3] |
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8
|
CAS
Superseded by part number: 7120024
|
| 4. |
895-11008
|
[3] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
CAS
Superseded by part number: 86624184
|
| 5. |
832-10408
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
CAS
Superseded by part number: 86528579
|
| 6. |
277042A1
|
[1] |
ANCHOR
|
CAS
BRACKET
|
| 7. |
614-10025
|
[2] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 9. |
832-10410
|
[2] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 190003888452
|
| 10. |
277034A1
|
[1] |
ADAPTER
|
CAS
|
| 11. |
277035A1
|
[1] |
SEAL
|
IH
|
| 12. |
277033A1
|
[2] |
HOSE
|
CAS
ASSY., 2000 mm supply and return
|
| 13. |
277037A1
|
[2] |
SEAL
|
CAS
1/2 in BSP
|
| 14. |
277036A1
|
[2] |
COUPLING, BREAK AWAY
|
CAS
|
| 14A. |
291354A1
|
[2] |
DUST CAP
|
CAS
Not Illustrated
|
| 15. |
277041A1
|
[2] |
HOSE
|
CAS
ASSY., 2400 mm hydraulic motor
|
| 16. |
277038A1
|
[2] |
HOSE
|
CAS
ASSY., 1280 mm tilt cylinder
|
| 8. |
895-11010
|
[2] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
CAS
11 x 21 x 2 mm Superseded by part number: 14496621
|
