纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.304.AM) - ENGINE OIL, PRESSURE CONTROL VALVE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
490 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504382195 | [1] | PRESSURE RELIEF VALVE | TORASSY, Incl 2, 3 |
| 1. | 5801491272 | [1] | VALVE | TORASSY, Incl 2, 3 |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONValve, Incl in 1 |
| 3. | 5135738 | [1] | O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro | TTF0.674 x 0.88 x 0.103 |
| 4. | 16673635 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TORM8 x 1.25 x 20 Superseded by part number: 16978124 |
| 4. | 16978124 | [2] | BOLT,Hex, M6 x 14mm | TORM6 x 14 |
