纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.304.AP) - BREATHER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
617 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801542914 | [1] | BREATHER | TORASSY, Incl 2 - 4 |
| 2. | 504050244 | [1] | SHAFT SEAL | TOR |
| 3. | 504325903 | [1] | O-RING,91.41mm ID x 3.47mm | TOR |
| 4. | NSS | [1] | NOT SERVICED SEPARATELY | CONBreather, Incl in 1 |
| 5. | 16978124 | [2] | BOLT,Hex, M6 x 14mm | TORM6 x 14 |
| 6. | 2854083 | [1] | BOLT,Flng, M6 x 1 x 30mm | TORM6 x 30 Superseded by part number: 16586025 |
| 7. | 5801522165 | [1] | PIPE FITTING | TOR |
| 8. | 5801554912 | [1] | PIPE | TOR |
| 9. | 2852197 | [4] | FLANGE NUT,M6 x 1 | TORM6 Superseded by part number: 17044625 |
| 10. | 17315290 | [1] | CLAMP | TOR |
| 11. | 5801567854 | [1] | RETAINER | TOR |
| 12. | 5801363192 | [1] | BUSHING | TOR |
| 13. | 504075145 | [1] | ELEMENT | TOR |
| 14. | 16867073 | [1] | SNAP RING | TOR |
| 15. | 5801572046 | [1] | SHAFT | TOR |
