纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.414.AC) - FAN, SUPPORT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
717 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504255374 | [1] | FAN HOUSING | TORASSY, Incl 2 - 8 |
| 2. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 3. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 4. | 32324 | [1] | SNAP RING,2.44", Int, #244 | GI |
| 5. | 504255371 | [1] | HUB | TOR |
| 6. | 2852172 | [1] | BOLT,Flng, M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 7. | 16673735 | [5] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 8. | NSS | [1] | NOT SERVICED SEPARATELY | CONSupport, Incl in 1 |
