凯斯零件查询(8640) - CASE IH BALE WRAPPER (1/97-12/97) (2-82) - LIFT ARM, 8640 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
842 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
276922A1
|
[1] |
ARM
|
CAS
order: 313841A1 order also: 1 x 313091A1, 1 x 313842A1 See Figure: 2-30
|
| 1. |
313841A1
|
[1] |
ARM
|
CAS
ASSY., Replaces: 276922A1
|
| 2. |
276387A1
|
[1] |
PIN
|
CAS
pivot
|
| 3. |
A30338
|
[3] |
PIN
|
CAS
linch 1/4 in Superseded by part number: 270184
|
| 4. |
276934A1
|
[1] |
PLUG
|
CAS
100 x 50 mm
|
| 5. |
276929A1
|
[1] |
BAR
|
CAS
ASSY.
|
| 6. |
276923A1
|
[2] |
PIN
|
CAS
|
| 7. |
276925A1
|
[1] |
PLATE ASSY.
|
CAS
|
| 8. |
276926A1
|
[2] |
BRACKET
|
CAS
|
| 9. |
276927A1
|
[2] |
PAD, RUBBER
|
IH
|
| 10. |
864-10060
|
[4] |
HEX SOC SCREW,M10 x 60mm, Cl 8.8
|
CAS
M10 x 60 Superseded by part number: 412412
|
| 11. |
840-1612
|
[8] |
SCREW,Pan, M6 x 12mm, Cl 4.8
|
CAS
Superseded by part number: 86511828
|
| 12. |
219-14
|
[2] |
LUBE NIPPLE,1/4" NPTF
|
CAS
|
