凯斯零件查询(8640) - CASE IH BALE WRAPPER (1/97-12/97) (2-86) - BALE MAT, 8640, - DBG0004009, 8650, - DBG0002009 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
430 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
277158A1
|
[1] |
FRAME
|
CAS
ASSY.
|
| 2. |
291350A1
|
[1] |
PLUG
|
CAS
1/4 in BSP
|
| 3. |
277163A1
|
[1] |
MAT
|
CAS
|
| 4. |
277160A1
|
[2] |
STRIP
|
CAS
PLATE
|
| 5. |
614-8030
|
[9] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 6. |
895-11008
|
[9] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
CAS
Superseded by part number: 86624184
|
| 7. |
832-10408
|
[9] |
NUT,M8 x 1.25, Cl 8.8
|
CAS
Superseded by part number: 86528579
|
| 8. |
814-10060
|
[2] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 120070
|
| 10. |
832-10410
|
[2] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 190003888452
|
| 11. |
277164A1
|
[2] |
BUSHING
|
CAS
SPACER
|
| 12. |
277168A1
|
[2] |
DAMPER
|
CAS
CYLIINDER
|
| 12A. |
277553A1
|
[2] |
KIT
|
CAS
package, seals Not Illustrated
|
| 13. |
614-6045
|
[3] |
BOLT,Hex, M6 x 1 x 45mm, Cl 8.8, Full Thd
|
CAS
BOLT, M6 x 45; 8.8 Superseded by part number: 15212821
|
| 14. |
832-10406
|
[3] |
NUT,M6 x 1, Cl 8
|
CAS
|
| 15. |
277165A1
|
[1] |
BAR
|
CAS
|
| 16. |
277166A1
|
[1] |
BAR
|
CAS
|
| 17. |
277167A1
|
[1] |
BAR
|
CAS
|
| 18. |
277177A1
|
[1] |
FITTING
|
CAS
tee
|
| 19. |
277170A1
|
[1] |
ADAPTER
|
CAS
|
| 20. |
277035A1
|
[2] |
SEAL
|
IH
|
| 21. |
277172A1
|
[2] |
HOSE
|
CAS
ASSY., 365 mm
|
| 22. |
277169A1
|
[1] |
VALVE
|
CAS
balance
|
| 23. |
277034A1
|
[1] |
ADAPTER
|
CAS
|
| 24. |
277174A1
|
[1] |
HOSE
|
CAS
ASSY., 570 mm
|
| 25. |
277171A1
|
[1] |
ADAPTER
|
CAS
|
| 26. |
277179A1
|
[1] |
SEAL
|
CAS
|
| 27. |
277180A1
|
[1] |
TANK
|
CAS
oil
|
| 9. |
895-11010
|
[2] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
CAS
11 x 21 x 2 mm Superseded by part number: 14496621
|
