纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (07-003-01[01]) - TRAVEL REDUCTION GEAR - REAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ND101767 | [1] | REDUCER | STA |
| 1. | ND101668 | [10] | BOLT | STAM10 x 25 |
| 2. | ND104076 | [2] | PLUG | STA |
| 3. | ND104058 | [1] | COVER | STA |
| 4. | ND104071 | [1] | O-RING | STA |
| 5. | ND104070 | [1] | PAD | STA |
| 6. | ND104065 | [1] | PINION | STA |
| 7. | ND104057 | [1] | PINION CARRIER | STA |
| 8. | ND104064 | [1] | PLANETARY GEAR | STA |
| 9. | ND104075 | [4] | BOLT | STA |
| 10. | ND104060 | [1] | PINION CARRIER | STA |
| 11. | ND104068 | [4] | RING | STA |
| 12. | ND104059 | [1] | BOX | STA |
| 13. | ND101646 | [1] | GASKET | STA |
| 14. | ND101630 | [1] | RING | STA |
| 15. | ND104061 | [1] | HUB | STA |
| 16. | ND101651 | [1] | O-RING | STA |
| 17. | ND104067 | [1] | COVER | STA |
| 18. | ND101665 | [3] | BOLT | STA |
| 19. | ND104062 | [1] | SHAFT | STA |
| 20. | ND101643 | [6] | BRAKE DISC | STA |
| 21. | ND101641 | [5] | DISC | STA |
| 22. | ND104069 | [1] | SPACER | STA |
| 23. | ND104079 | [1] | RING | STA3 x 121,11 |
| 24. | ND104072 | [1] | O-RING | STA3,53 x 120,24 |
| 25. | ND104077 | [1] | RING | STA3 x 104,93 |
| 26. | ND101656 | [1] | O-RING | STA3,53 x 104,37 |
| 27. | ND104073 | [1] | O-RING | STA3,53 x 129,77 Superseded by part number: 84314738 |
| 28. | ND104078 | [1] | RING | STA3 x 130,63 Superseded by part number: 84314748 |
| 29. | ND104063 | [1] | PISTON | STA |
| 30. | ND101639 | [18] | SPRING | STA |
| 31. | ND104066 | [1] | RACE | STA |
| 32. | ND104074 | [1] | SNAP RING | STA |
| 33. | ND101654 | [1] | O-RING | STA4 x 150 |
| 34. | ND101648 | [2] | BOLT | STAM16 x 40 |
