纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (10-002-00[01]) - HYDRAULIC CIRCUIT - VIBRATION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
434 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | ND053294 | [2] | SNAP RING | STA |
| 12. | ND062109 | [1] | HYD CONNECTOR | STA |
| 13. | ND062181 | [1] | HYD CONNECTOR | STA |
| 14. | ND062138 | [2] | HYD CONNECTOR | STA |
| 15. | ND062135 | [1] | HYD CONNECTOR | STA |
| 16. | ND062367 | [1] | HYD CONNECTOR | STA |
| 18. | ND062378 | [1] | PLUG | STA |
| 20. | ND062008 | [8] | HALF-COLLAR | STA |
| 21. | ND079933 | [4] | O-RING | STA |
| 24. | ND061515 | [1] | FLEXIBLE HOSE | STA3650mm |
| 26. | ND061516 | [1] | HOSE,550.00 mm | STA |
| 27. | ND061517 | [1] | HOSE,750.00 mm | STA |
| 29. | ND061518 | [1] | FLEXIBLE HOSE | STA3150mm |
| 30. | ND061519 | [1] | FLEXIBLE HOSE | STA3200mm |
| 34. | ND034059 | [8] | BOLT | STA |
| 35. | ND034050 | [8] | SCREW | STA |
| 48. | ND106910 | [10] | STRAP | STA370mm |
