纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (10-012-00[01]) - HYDRAULIC PUMP -TRAVEL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
599 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ND090919 | [1] | HYDRAULIC PUMP | STA |
| 1. | ND102368 | [1] | BOX | STA |
| 2. | ND102503 | [1] | BEARING | STA |
| 3. | ND102301 | [2] | PIN | STA |
| 4. | ND102474 | [1] | PLUG | STA |
| 4A. | ND102311 | [1] | O-RING | STA |
| 6. | ND102516 | [1] | BLOCK | STA |
| 7. | ND102526 | [9] | PISTON | STA |
| 8. | ND102547 | [1] | PLATE | STA |
| 9. | ND102325 | [2] | GUIDE | STA |
| 10. | ND102324 | [4] | SPACER | STA |
| 11. | ND102315 | [4] | SCREW | STA |
| 12. | ND102616 | [1] | SERVICE KIT | STA |
| 13. | ND102612 | [1] | LEVER | STA |
| 14. | ND102475 | [1] | THRUST PLATE | STA |
| 15. | ND102497 | [1] | SCREW | STA |
| 16. | ND102553 | [1] | GUIDE | STA |
| 17. | ND102571 | [1] | SCREW | STA |
| 18. | ND102521 | [1] | SPACER | STA |
| 19. | ND102494 | [1] | PIN | STA |
| 20. | ND102517 | [1] | CONNECTING LINK | STA |
| 21. | ND102642 | [1] | PIN | STA |
| 22. | ND102490 | [1] | SPRING | STA |
| 23. | ND102380 | [1] | COVER | STA |
| 24. | ND102395 | [1] | COVER | STA |
| 25. | ND102617 | [1] | LINK | STA |
| 26. | ND102350 | [2] | WASHER | STA |
| 27. | ND102601 | [2] | GUIDE | STA |
| 28. | ND102398 | [2] | O-RING | STA |
| 29. | ND102507 | [1] | O-RING | STA |
| 30. | ND102366 | [6] | SCREW | STA |
| 31. | ND102493 | [1] | PLUG | STA |
| 31A. | ND102299 | [1] | O-RING | STA |
| 32. | ND102326 | [2] | SPRING | STA |
| 33. | ND102352 | [2] | SPRING | STA |
| 34. | ND102477 | [1] | PISTON | STA |
| 35. | ND102502 | [2] | O-RING | STA |
| 36. | ND102411 | [2] | SEAL | STA |
| 37. | ND102369 | [1] | BLOCK | STA |
| 38. | ND102353 | [2] | O-RING | STA |
| 39. | ND102505 | [2] | O-RING | STA |
| 40. | ND102385 | [1] | COVER | STA |
| 42. | ND102615 | [1] | GASKET | STA |
| 43. | ND102307 | [1] | PLUG | STA |
| 48. | ND102550 | [1] | SCREW | STA |
| 49. | ND102363 | [1] | SCREW | STA |
| 50. | ND102549 | [1] | SCREW | STA |
| 51. | ND102426 | [1] | SPACER | STA |
| 52. | ND102427 | [1] | SPACER | STA |
| 53. | ND102321 | [1] | PLATE | STA |
| 54. | ND102487 | [6] | SCREW | STA |
| 55. | ND102522 | [1] | COUPLING | STA |
| 56. | ND102506 | [1] | O-RING | STA |
| 57. | ND102309 | [1] | O-RING | STA |
| 58. | ND102495 | [1] | ADAPTER | STA |
| 59. | ND102496 | [4] | WASHER | STA |
| 60. | ND102333 | [4] | SCREW | STA |
| 61. | ND102538 | [1] | O-RING | STA |
| 62. | ND102511 | [1] | COVER | STA |
| 63. | ND102482 | [2] | SCREW | STA |
| 64. | ND102386 | [1] | SCREW | STA |
| 65. | ND102298 | [1] | O-RING | STA |
| 66. | ND102501 | [1] | SPRING | STA |
| 67. | ND102334 | [1] | CONE | STA |
| 68. | ND102337 | [1] | NUT | STA |
| 69. | ND102509 | [1] | BALL BEARING | STA Superseded by part number: 5138660 |
| 70. | ND102491 | [1] | SNAP RING | STA |
| 71. | ND102567 | [1] | RING | STA |
| 72. | ND102492 | [1] | SEAL | STA |
| 73. | ND102510 | [1] | O-RING | STA |
| 74. | ND102566 | [1] | PLATE | STA |
| 75. | ND102305 | [3] | SCREW | STA |
| 76. | ND102466 | [1] | CONTROL | STA |
| 77. | ND102572 | [1] | GASKET | STA |
| 78. | ND102603 | [1] | CONNECTING LINK | STA |
| 79. | ND102513 | [6] | SCREW | STA |
| 80. | ND102525 | [1] | REDUCER | STA |
| 80A. | ND102300 | [1] | O-RING | STA |
| 82. | ND102508 | [2] | HYDRAULIC VALVE | STA |
| 83. | ND102425 | [2] | PLUG | STA |
| 84. | ND102637 | [1] | PLUG | STA |
| 85. | ND102504 | [1] | SPRING | STA |
| 86. | ND102520 | [1] | SPRING CUP | STA |
| 87. | ND102454 | [1] | GUIDE | STA |
| 88. | ND102453 | [1] | GUIDE | STA |
| 89. | ND102381 | [1] | SLEEVE | STA |
| 90. | ND102360 | [3] | SCREW | STA |
| 93. | ND102469 | [1] | COVER | STA |
| 94. | ND102530 | [1] | PRESSURE RELIEF VALVE | STA |
| 95. | ND102515 | [1] | SHAFT | STA |
| 96. | ND102318 | [2] | O-RING | STA |
| 97. | ND102304 | [1] | O-RING | STA |
| 98. | ND102570 | [1] | O-RING | STA |
| 99. | ND102518 | [1] | HYD CONNECTOR | STA |
| 100. | ND102528 | [2] | PRESSURE RELIEF VALVE | STA |
| 101. | ND102322 | [3] | FILTER | STA |
| . . | ND102328 | [1] | SEAL KIT | STA |
| . . | ND102519 | [1] | KIT | STA |
| . . | ND102614 | [1] | CONTROL | STA |
