纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (10-013-00[01]) - HYDRAULIC PUMP - VIBRATIONS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
575 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ND090921 | [1] | HYDRAULIC PUMP | STA |
| 1. | ND102441 | [1] | BOX | STA |
| 2. | ND102340 | [1] | BEARING | STA |
| 3. | ND102301 | [2] | PIN | STA |
| 4. | ND102474 | [1] | PLUG | STA |
| 4A. | ND102311 | [1] | O-RING | STA |
| 6. | ND102317 | [1] | PLUG | STA |
| 6A. | ND102298 | [1] | O-RING | STA |
| 7. | ND102322 | [3] | FILTER | STA |
| 8. | ND102556 | [1] | CYLINDER BLOCK | STA |
| 9. | ND102523 | [9] | PISTON ASSY | STA |
| 10. | ND102546 | [1] | RETAINER | STA |
| 11. | ND102319 | [2] | GUIDE | STA |
| 12. | ND102357 | [4] | SPACER | STA |
| 13. | ND102488 | [4] | SCREW | STA |
| 14. | ND102554 | [1] | LOCK CYLINDER | STA |
| 15. | ND102388 | [1] | LEVER | STA |
| 16. | ND102433 | [1] | THRUST PLATE | STA |
| 17. | ND102486 | [1] | SCREW | STA |
| 18. | ND102557 | [1] | GUIDE | STA |
| 19. | ND102345 | [1] | SCREW | STA |
| 20. | ND102521 | [1] | SPACER | STA |
| 21. | ND102320 | [1] | PIN | STA |
| 22. | ND102485 | [1] | CONNECTING LINK | STA |
| 23. | ND102432 | [1] | SCREW | STA |
| 24. | ND102489 | [1] | SPRING | STA |
| 25. | ND102379 | [1] | COVER | STA |
| 26. | ND102402 | [1] | COVER | STA |
| 27. | ND102542 | [1] | PIVOT | STA |
| 28. | ND102532 | [2] | SPRING CUP | STA |
| 29. | ND102349 | [2] | WASHER | STA |
| 30. | ND102401 | [2] | GUIDE | STA |
| 31. | ND102478 | [2] | NUT | STA |
| 32. | ND102558 | [1] | O-RING | STA |
| 33. | ND102423 | [6] | SCREW | STA |
| 35. | ND102323 | [2] | SPRING | STA |
| 36. | ND102452 | [1] | GUIDE | STA |
| 37. | ND102451 | [1] | GUIDE | STA |
| . . | ND102343 | [1] | PISTON | STA |
| 38. | ND102428 | [1] | PISTON | STA |
| 39. | ND102342 | [2] | O-RING | STA |
| 40. | ND102410 | [2] | SEAL | STA |
| 41. | ND102484 | [1] | BLOCK | STA |
| 42. | ND102524 | [2] | O-RING | STA |
| 43. | ND102327 | [2] | O-RING | STA |
| 44. | ND102378 | [1] | SLEEVE | STA |
| 45. | ND102424 | [3] | SCREW | STA |
| 48. | ND102406 | [1] | COVER | STA |
| 49. | ND102338 | [1] | BUSHING | STA |
| 50. | ND102483 | [1] | BUSHING | STA |
| 51. | ND102464 | [1] | GASKET | STA |
| 52. | ND102307 | [1] | PLUG | STA |
| 54. | ND102449 | [1] | SCREW | STA |
| 55. | ND102346 | [1] | SCREW | STA |
| 56. | ND102335 | [1] | SPACER | STA |
| 57. | ND102468 | [1] | SHAFT | STA |
| 58. | ND102321 | [1] | PLATE | STA |
| 59. | ND102487 | [6] | SCREW | STA |
| 60. | ND102405 | [1] | REPAIR KIT | STA |
| 61. | ND102506 | [1] | O-RING | STA |
| 62. | ND102407 | [4] | SCREW | STA |
| 63. | ND102636 | [1] | COVER | STA |
| 64. | ND102530 | [1] | PRESSURE RELIEF VALVE | STA |
| 65. | ND102386 | [1] | SCREW | STA |
| 67. | ND102501 | [1] | SPRING | STA |
| 68. | ND102334 | [1] | CONE | STA |
| 69. | ND102337 | [1] | NUT | STA |
| 70. | ND102347 | [1] | BALL BEARING | STA |
| 71. | ND102481 | [1] | SNAP RING | STA |
| 72. | ND102331 | [1] | GASKET | STA |
| 73. | ND102316 | [1] | SEAL | STA |
| 74. | ND102568 | [1] | O-RING | STA |
| 75. | ND102330 | [1] | PLATE | STA |
| 76. | ND102548 | [1] | SCREW | STA |
| 77. | ND102332 | [1] | SHAFT | STA |
| 78. | ND102508 | [2] | HYDRAULIC VALVE | STA |
| 79. | ND102425 | [2] | PLUG | STA |
| 80. | ND102637 | [1] | PLUG | STA |
| 81. | ND102504 | [1] | SPRING | STA |
| 82. | ND102520 | [1] | SPRING CUP | STA |
| 83. | ND102528 | [1] | PRESSURE RELIEF VALVE | STA |
| 85. | ND102493 | [1] | PLUG | STA |
| 85A. | ND102299 | [1] | O-RING | STA |
| 86. | ND102344 | [1] | GASKET | STA |
| 87. | ND102514 | [6] | SCREW | STA |
| 88. | ND102312 | [1] | WASHER | STA |
| 89. | ND102480 | [1] | SEAL | STA |
| 90. | ND102465 | [1] | PLUG | STA |
| 93. | ND102398 | [1] | O-RING | STA |
| 94. | ND102476 | [1] | SCREW | STA |
| 95. | ND102336 | [1] | COVER | STA |
| 96. | ND102447 | [1] | CONTROL VALVE | STA |
| 97. | ND102399 | [1] | PLATE | STA |
| 98. | ND102479 | [1] | SOLENOID VALVE | STA |
| 99. | ND102308 | [4] | O-RING | STA |
| 100. | ND102313 | [4] | SCREW | STA |
| 101. | ND102400 | [1] | SOLENOID VALVE | STA |
| . . | ND102329 | [1] | SEAL KIT | STA |
