| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
210445C1
|
[1] |
BELL HOUSING
|
IH
GONG, brass trip
|
| . . |
120697
|
[2] |
SCREW, 1/4-20 x 3/4 znd flat-hd slt-mach
|
|
| . . |
938016R1
|
[2] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4-20 znd hex. lock Superseded by part number: 523282
|
| 2. |
512749R1
|
[1] |
HOOK
|
IH
S-HOOK
|
| 3. |
23331SA
|
[1] |
SPRING
|
IH
|
| 4. |
670595R91
|
[2] |
TERMINAL CONNECTOR
|
IH
CLAMP ASSY, cable
|
| . . |
492-11025
|
[4] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
217784R1
|
[4] |
WASHER, .266 x .500 x .054
|
|
| 5. |
210446C1
|
[1] |
CABLE
|
IH
trip
|
