凯斯零件查询(241) - INTERNATIONAL HARVESTER BIGROLL ROUND BALER (1/74-12/79) (A-40[B]) - BALE COUNTER ATTACHMENT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
475 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
495046R92
|
[1] |
COUNTER
|
IH
W/ATTACHING HARDWARE, bale
|
| 2. |
662364R1
|
[1] |
BRACKET
|
IH
MOUNT, bale counter
|
| . . |
120583
|
[2] |
SCREW,Sl Rnd Hd, 1/4" - 20 x 5/8"
|
IH
1/4-20 x 5/8 znd slt rd-hd mach. Superseded by part number: 86511931
|
| . . |
938016R1
|
[2] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4-20 znd hex. lock Superseded by part number: 523282
|
| 3. |
495525R1
|
[1] |
SPRING
|
IH
bale counter
|
| . . |
125637
|
[1] |
COTTER PIN,1/8" x 2"
|
IH
PIN, SPLIT (COTTER), 1/8" x 2" Superseded by part number: 86523955
|
