纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-004-00[01]) - HYDRAULIC CIRCUIT, TRAVEL -REAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
741 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | ND031345 | [2] | HYD CONNECTOR | STA |
| 7. | ND103175 | [1] | BRACKET | STA |
| 10. | ND103197 | [1] | FLEXIBLE HOSE | STA |
| 11. | ND103198 | [1] | FLEXIBLE HOSE | STA |
| 12. | ND103199 | [1] | FLEXIBLE HOSE | STA |
| 16. | ND103201 | [1] | FLEXIBLE HOSE | STA |
| 17. | ND103202 | [1] | FLEXIBLE HOSE | STA |
| 18. | ND103203 | [1] | FLEXIBLE HOSE | STA |
| 22. | ND067795 | [1] | VALVE | STA |
| 26. | ND062153 | [3] | HYD CONNECTOR | STA |
| 31. | ND062135 | [4] | HYD CONNECTOR | STA |
| 36. | ND062294 | [1] | HYD CONNECTOR | STA |
| 37. | ND062335 | [1] | HYD CONNECTOR | STA |
| 42. | ND062247 | [1] | HYD CONNECTOR | STA |
| 47. | ND062391 | [2] | REDUCER | STA |
| 48. | ND062433 | [2] | RESTRICTOR | STA |
| 59. | ND062039 | [6] | SEAL | STA Superseded by part number: 11266811 |
| 61. | ND062037 | [6] | SEAL | STA |
| 62. | ND062046 | [6] | NUT | STA Superseded by part number: 11260711 |
| 64. | ND062058 | [6] | NUT | STA |
| 72. | ND103076 | [1] | FLEXIBLE HOSE | STA |
| 73. | ND103077 | [1] | HOSE | STA |
| 78. | ND061508 | [1] | FLEXIBLE HOSE | STA1800mm |
| 79. | ND061509 | [1] | FLEXIBLE HOSE | STA1700 mm |
| 85. | ND064802 | [1] | SLEEVE | STA |
| 86. | ND064836 | [1] | SLEEVE | STA |
| 88. | ND064797 | [4] | SLEEVE | STA |
| 90. | ND064799 | [1] | CLAMP | STA |
| 94. | ND064807 | [1] | CLAMP | STA |
| 95. | ND064834 | [1] | COVER | STA |
| 97. | ND073366 | [2] | WASHER | STA27 x 36 x 2 |
| 100. | ND024231 | [8] | BOLT | STAM6 x 22 |
| 101. | ND024233 | [2] | BOLT | STAM6 x 28 |
| 105. | ND021184 | [1] | BOLT | STAM8 x 35 |
| 106. | ND024252 | [1] | BOLT | STAM8 x 65 |
| 109. | ND021302 | [2] | BOLT | STAM10 x 25 |
| 118. | ND029248 | [10] | WASHER | STAID 6,4 |
| 121. | ND035941 | [2] | WASHER | STAID 10 |
| 124. | ND106910 | [2] | STRAP | STA |
