纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-003-00[01]) - HYDRAULIC CIRCUIT, TRAVEL - DRUM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
691 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND031991 | [1] | SUPPORT | STA |
| 2. | ND103340 | [1] | SUPPORT | STA |
| 5. | ND052985 | [3] | STUD | STA |
| 7. | ND103175 | [1] | BRACKET | STA |
| 14. | ND103200 | [1] | FLEXIBLE HOSE | STA |
| 22. | ND067795 | [1] | VALVE | STA |
| 26. | ND062153 | [2] | HYD CONNECTOR | STA |
| 27. | ND062173 | [3] | HYD CONNECTOR | STA |
| 28. | ND062196 | [1] | HYD CONNECTOR | STA |
| 31. | ND062135 | [2] | HYD CONNECTOR | STA |
| 32. | ND062136 | [1] | HYD CONNECTOR | STA |
| 37. | ND062335 | [1] | HYD CONNECTOR | STA |
| 39. | ND062426 | [1] | HYD CONNECTOR | STA |
| 40. | ND062298 | [1] | HYD CONNECTOR | STA |
| 44. | ND062452 | [1] | PLUG | STA |
| 46. | ND062428 | [1] | RESTRICTOR | STA |
| 48. | ND062433 | [1] | RESTRICTOR | STA |
| 51. | ND062277 | [1] | QUICK FEMALE COUPLING | STA Superseded by part number: ND112940 |
| 52. | ND062280 | [1] | QUICK MALE COUPLING | STA Superseded by part number: ND112941 |
| 54. | ND062008 | [8] | HALF-COLLAR | STA |
| 55. | ND062009 | [1] | FLANGE | STA |
| 56. | ND079933 | [1] | O-RING | STA |
| 57. | ND079934 | [2] | O-RING | STA |
| 60. | ND062033 | [2] | SEAL | STA |
| 63. | ND062047 | [2] | NUT | STA |
| 67. | ND061504 | [1] | FLEXIBLE HOSE | STA3250mm |
| 69. | ND061225 | [1] | FLEXIBLE HOSE | STA400mm Superseded by part number: ND061504 |
| 71. | ND104859 | [1] | FLEXIBLE HOSE | STA |
| 75. | ND061540 | [1] | FLEXIBLE HOSE | STA500mm |
| 76. | ND061145 | [1] | FLEXIBLE HOSE | STA650mm |
| 81. | ND104949 | [1] | FLEXIBLE HOSE | STA3450mm |
| 82. | ND061507 | [1] | FLEXIBLE HOSE | STA3750mm |
| 89. | ND064786 | [2] | CLAMP | STA |
| 90. | ND064799 | [1] | CLAMP | STA |
| 91. | ND061999 | [2] | CLAMP | STA |
| 92. | ND064809 | [1] | CLAMP | STA |
| 100. | ND024231 | [2] | BOLT | STAM6 x 22 |
| 101. | ND024233 | [2] | BOLT | STAM6 x 28 |
| 102. | ND024235 | [2] | BOLT | STAM5 x 35 |
| 103. | ND024234 | [2] | BOLT | STAM6 x 40 |
| 108. | ND021197 | [8] | BOLT | STAM10 x 45 |
| 109. | ND021302 | [2] | BOLT | STAM10 x 25 |
| 110. | ND024259 | [8] | BOLT | STAM10 x 30 |
| 112. | ND034063 | [8] | BOLT | STA |
| 115. | ND021847 | [3] | NUT | STAM6 |
| 118. | ND029248 | [18] | WASHER | STAID 6,4 |
| 119. | ND029309 | [3] | SPRING WASHER | STAID 6,1 |
| 121. | ND035941 | [4] | WASHER | STAID10 |
| 124. | ND106910 | [15] | STRAP | STA |
