纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-009-00[01]) - HYDRAULIC CIRCUIT PRESSURE TEST POINT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
736 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND031315 | [1] | BLOCK | STA |
| 4. | ND062197 | [6] | HYD CONNECTOR | STA |
| 5. | ND062137 | [4] | HYD CONNECTOR | STA |
| 10. | ND062431 | [5] | HYD CONNECTOR | STA |
| 11. | ND062258 | [6] | HYD CONNECTOR | STA Superseded by part number: 47732245 |
| 14. | ND061703 | [1] | HOSE,900.00 mm | STA |
| 15. | ND061532 | [1] | HOSE,350.00 mm | STA |
| 16. | ND061533 | [1] | HOSE | STA550mm |
| 17. | ND061534 | [1] | HOSE,400.00 mm | STA |
| 18. | ND061535 | [1] | HOSE,450.00 mm | STA |
| 19. | ND061705 | [1] | HOSE,700.00 mm | STA |
| 21. | ND035940 | [2] | SPRING WASHER | STAID 8 |
| 23. | ND024245 | [2] | BOLT | STAM8 x 25 |
