纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-010-00[01]) - HYDRAULIC CIRCUIT, DOZER BLADE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
250 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND098269 | [1] | SUPPORT | STA |
| 3. | ND051432 | [2] | CLAMP | STA Superseded by part number: 47482802 |
| 4. | ND096307 | [1] | BLOCK | STA |
| 5. | ND050613 | [1] | HYD CONNECTOR | STA |
| 6. | ND096308 | [1] | BLOCK | STA |
| 7. | ND098290 | [1] | PLATE | STA |
| 8. | ND098282 | [1] | CLAMP | STA |
| 9. | ND096306 | [1] | HYD CONNECTOR | STA |
| 10. | ND042815 | [2] | WASHER | STAID 12 Superseded by part number: ND029267 |
| 11. | ND098270 | [1] | FLEXIBLE HOSE | STA |
| 15. | ND099898 | [1] | FLEXIBLE HOSE | STA |
| 16. | ND099899 | [1] | FLEXIBLE HOSE | STA |
| 18. | ND099900 | [1] | FLEXIBLE HOSE | STA |
| 19. | ND099901 | [1] | FLEXIBLE HOSE | STA |
| 20. | ND099902 | [1] | FLEXIBLE HOSE | STA |
| 21. | ND099903 | [1] | FLEXIBLE HOSE | STA |
| 25. | ND067967 | [1] | HYDRAULIC PUMP | STA |
| 26. | ND068139 | [2] | HYDRAULIC CYLINDER | STA |
| 27. | ND067850 | [1] | CONTROL VALVE | STA |
| 28. | ND068008 | [1] | VALVE | STA |
| 29. | ND067848 | [1] | JOYSTICK | STA |
| 33. | ND062124 | [1] | HYD CONNECTOR | STA |
| 34. | ND062212 | [1] | HYD CONNECTOR | STA |
| 35. | ND062110 | [1] | HYD CONNECTOR | STA |
| 36. | ND062171 | [1] | HYD CONNECTOR | STA |
| 37. | ND062185 | [1] | HYD CONNECTOR | STA |
| 40. | ND062413 | [2] | HYD CONNECTOR | STA |
| 42. | ND062467 | [4] | BOLT | STA |
| 44. | ND079933 | [1] | O-RING | STA |
| 45. | ND079934 | [4] | O-RING | STA |
| 46. | ND079806 | [1] | RING | STA |
| 48. | ND079514 | [1] | GROMMET | STA |
| 50. | ND062013 | [2] | HALF-COLLAR | STA |
| 53. | ND061712 | [2] | HOSE,320.00 mm | STA |
| 54. | ND061713 | [2] | HOSE,330.00 mm | STA |
| 55. | ND061714 | [1] | FLEXIBLE HOSE | STA1550mm |
| 56. | ND061715 | [1] | FLEXIBLE HOSE | STA1550mm |
| 57. | ND061716 | [1] | FLEXIBLE HOSE | STA1700mm |
| 58. | ND061728 | [1] | FLEXIBLE HOSE | STA1700mm |
| 60. | ND061717 | [1] | FLEXIBLE HOSE | STA2000mm |
| 62. | ND060971 | [1] | FLEXIBLE HOSE | STA1200mm |
| 64. | ND061718 | [1] | FLEXIBLE HOSE | STA1350mm |
| 67. | ND064847 | [8] | HOSE | STA |
| 68. | ND064833 | [8] | COVER | STA |
| 69. | ND064831 | [8] | SUPPORT | STA |
| 72. | ND062047 | [8] | NUT | STA |
| 73. | ND062033 | [8] | SEAL | STA |
| 74. | ND073364 | [1] | SEAL | STA27 x 32 x1 |
| 75. | ND073349 | [1] | SEAL | STA13 x 17 x 1,5 |
| 79. | ND021173 | [4] | BOLT | STAM6 x 30 |
| 80. | ND021174 | [8] | BOLT | STAM6 x 35 |
| 81. | ND021294 | [4] | BOLT | STAM8 x 20 |
| 82. | ND021296 | [2] | BOLT | STAM8 x 30 |
| 83. | ND024250 | [2] | BOLT | STAM8 x 50 |
| 86. | ND021303 | [2] | BOLT | STAM10 x 30 |
| 87. | ND021195 | [4] | BOLT | STAM10 x 35 |
| 88. | ND021203 | [8] | BOLT,Hex, M10 x 80mm | STAM10 x 80 |
| 89. | ND021215 | [2] | BOLT | STAM12 x 80 |
| 92. | ND021848 | [8] | NUT | STAM8 Superseded by part number: ND034087 |
| 93. | ND021849 | [2] | NUT | STAM10 Superseded by part number: ND034088 |
| 96. | ND029309 | [12] | SPRING WASHER | STAID 6,1 |
| 97. | ND035940 | [8] | SPRING WASHER | STAID 8 |
| 98. | ND035941 | [10] | WASHER | STAID 10 |
