凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (00.00RB216) - MAINTENANCE PARTS, MAIN FRAME ROLLS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1002 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
1.772" ID, RH, Drive roll
|
| 2. |
86978595
|
[1] |
BEARING ASSY
|
PA
1.969" ID, LH, Drive roll
|
| 2. |
86590752
|
[1] |
BEARING ASSY
|
NH
1.969" ID, LH, Drive roll Superseded by part number: 87660333
|
| 3. |
86590753
|
[2] |
BEARING ASSY
|
NH
1.575" ID, Floor roll, Rotor
|
| 3. |
87027838
|
[2] |
BEARING ASSY
|
PA
40 mm ID, Round, Floor roll, Stuffer feeder
|
| 4. |
87660306
|
[4] |
WEAR PLATE
|
NH
|
| 5. |
86978603
|
[2] |
BEARING ASSY,45mm ID x 85mm OD x 22mm W
|
PA
& Collar, Starter roll
|
| 6. |
86837676
|
[4] |
FLANGED BEARING
|
PA
Starter roll Superseded by part number: 86979948
|
| 7. |
86610638
|
[2] |
BEARING ASSY,45mm ID
|
NH
1.772" ID, Starter roll
|
| 9. |
286909
|
[2] |
BALL BEARING,38.11mm Hex x 84.99mm OD x 30mm W
|
NH
1-1/2" Hex Bore, Fixed roll Superseded by part number: 47577178
|
| 10. |
8050825
|
[2] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Belt tension, Front serpentine roller Superseded by part number: F82059
|
| 11. |
86500662
|
[2] |
BEARING ASSY
|
NH
Belt tension, Rear serpentine roller
|
| 12. |
9845576
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
NH
Backwrap roller Superseded by part number: 84330072
|
