凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (00.00RB217) - MAINTENANCE PARTS, PIVOT SLEDGE ROLLS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
810 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
RH, Sledge pivot roll
|
| 2. |
412441
|
[1] |
ROLLER BEARING,40mm ID x 80mm OD x 21mm W, Round Bore
|
PA
& collar, RH, Pivot roll
|
| 3. |
9848489
|
[2] |
BEARING ASSY,73 mm ID x 132.1976 mm OD x 38.10 mm, Round Bore
|
NH
Sledge follower roll, Smooth Superseded by part number: 47531138
|
| 4. |
86553396
|
[2] |
BEARING ASSY,30.23mm ID x 90mm OD x 30.2mm W, SQUARE BORE
|
NH
Sledge follower roll, Loop, (5)
|
| 5. |
86548282
|
[2] |
BALL BEARING,29.41mm ID x 90mm OD x 30.2mm W, Square Bore
|
NH
|
| 6. |
86636892
|
[1] |
FLANGE
|
NH
RH, Sledge stripper roll
|
| 7. |
86614686
|
[2] |
GEAR
|
NH
Roll, 24T, LH, Sledge stripper & pivot rolls Superseded by part number: 87052121
|
| 8. |
9806931
|
[1] |
IDLER GEAR,17T
|
NH
17T, Sledge roll drive, (9)
|
| 9. |
9808112
|
[1] |
BALL BEARING,34.99mm ID x 71.88mm OD x 25mm W
|
NH
|
| 10. |
9803325
|
[2] |
SUPPORT
|
NH
LH, Sledge stripper & pivot rolls (Dimple roll)
|
| 11. |
87385929
|
[1] |
RUBBER STRIP,1140mm L x 112mm W x 7.5mm Thk
|
PA
1140 x 89
|
| 12. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
Silage/High moisture
|
| 12. |
86626880
|
[1] |
SCRAPER BLADE
|
PA
|
| 13. |
87398962
|
[2] |
HUB,12.5mm ID x 47.42mm OD x 13.2mm L
|
PA
Sledge stripper roll
|
