纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-013-00[01]) - HYDRAULIC PUMP - VIBRATIONS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
691 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ND090929 | [1] | HYDRAULIC PUMP | STA |
| 1. | ND102607 | [1] | PRESSURE RELIEF VALVE | STA |
| 2. | ND102646 | [1] | O-RING | STA |
| 3. | ND102608 | [1] | DIAPHRAGM | STA |
| 4. | ND102659 | [1] | PLUG | STA |
| 6. | ND102662 | [1] | PLUG | STA |
| 7. | ND102660 | [1] | PLUG | STA |
| 9. | ND102683 | [3] | BREATHER | STA |
| 10. | ND102591 | [1] | COVER | STA |
| 11. | ND102621 | [1] | BUSHING | STA |
| 12. | ND102590 | [1] | GASKET | STA |
| 13. | ND102620 | [1] | BUSHING | STA |
| 14. | ND102658 | [1] | PLUG | STA |
| 18. | ND102676 | [1] | SCREW | STA |
| 19. | ND102632 | [1] | SPACER | STA |
| 20. | ND102633 | [1] | CLIP | STA |
| 21. | ND102680 | [1] | WASHER | STA |
| 22. | ND102675 | [1] | SCREW | STA |
| 23. | ND102627 | [1] | SPACER | STA |
| 24. | ND102639 | [1] | SHAFT | STA |
| 25. | ND102625 | [1] | PLATE | STA |
| 26. | ND102667 | [6] | SCREW | STA |
| 27. | ND102636 | [1] | COVER | STA |
| 29. | ND102649 | [1] | O-RING | STA |
| 30. | ND102671 | [4] | SCREW | STA |
| 31. | ND102655 | [1] | O-RING | STA |
| 32. | ND102596 | [1] | SEAL KIT | STA |
| 33. | ND102679 | [1] | SEAL | STA |
| 34. | ND102651 | [1] | O-RING | STA |
| 35. | ND102585 | [1] | PLATE | STA |
| 36. | ND102673 | [3] | SCREW | STA |
| 37. | ND102443 | [1] | CONTROL VALVE | STA |
| 38. | ND102629 | [1] | GASKET | STA |
| 39. | ND102674 | [6] | SCREW | STA |
| 40. | ND102653 | [1] | O-RING | STA |
| 41. | ND102623 | [2] | HYDRAULIC VALVE | STA |
| 42. | ND102664 | [2] | PLUG | STA |
| 43. | ND102619 | [1] | SPRING | STA |
| 44. | ND102624 | [1] | SPRING CUP | STA |
| 45. | ND102465 | [1] | PLUG | STA |
| 48. | ND102618 | [2] | PRESSURE RELIEF VALVE | STA |
