纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (10-017-00[01]) - TRAVEL MOTOR - REGULATOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
561 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ND090792 | [1] | HYDRAULIC MOTOR | STA |
| 1. | ND102421 | [1] | PISTON | STA |
| 2. | ND102392 | [1] | O-RING | STA |
| 3. | ND102418 | [1] | SEAL | STA |
| 4. | ND102404 | [1] | PISTON | STA |
| 5. | ND102403 | [1] | COVER | STA |
| 6. | ND102474 | [1] | PLUG | STA |
| 7. | ND102422 | [2] | PLUG | STA |
| 8. | ND102498 | [8] | BOLT | STA |
| 9. | ND102355 | [1] | O-RING | STA |
| 10. | ND102552 | [5] | SEAL | STA |
| 11. | ND103353 | [1] | PLUG | STA |
| 12. | ND103356 | [2] | SPRING | STA |
| 13. | ND103355 | [2] | SPRING CUP | STA |
| 14. | ND102356 | [1] | PISTON | STA |
| 15. | ND102298 | [1] | O-RING | STA |
| 16. | ND102391 | [1] | SOLENOID VALVE | STA |
| 17. | ND102394 | [6] | PLUG | STA |
| 19. | ND102390 | [4] | BOLT | STA |
| 20. | ND102446 | [1] | VALVE BLOCK (USED) | STA |
| 21. | ND102416 | [1] | PORT | STA |
| 22. | ND102448 | [2] | PORT | STA |
| 23. | ND103354 | [1] | PLUG | STA |
| 24. | ND102376 | [1] | GASKET | STA |
| 25. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| . . | ND102450 | [1] | CONTROL VALVE | STA |
