纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (12-002-00[01]) - LINKAGE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1018 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND011563 | [1] | SUPPORT | STA |
| 2. | ND011554 | [1] | SUPPORT | STA |
| 3. | ND011572 | [1] | HUB | STA |
| 6. | ND103176 | [1] | SERVICE KIT | STA |
| 10. | ND030604 | [2] | FLANGE | STA |
| 11. | ND030600 | [2] | COVER | STA |
| 12. | ND030641 | [2] | SHOULDERED SHAFT | STA |
| 13. | ND052237 | [2] | BUSHING | STA |
| 15. | ND051966 | [4] | PLATE | STA |
| 16. | ND051968 | [8] | PLATE | STA |
| 17. | ND052231 | [2] | COVER PLATE | STA |
| 18. | ND048878 | [4] | WASHER | STA |
| 19. | ND052247 | [2] | COVER PLATE | STA |
| 20. | ND052258 | [6] | WASHER | STA |
| 23. | ND068780 | [1] | BEARING | STA |
| 24. | ND068998 | [2] | BALL BEARING | STA |
| 25. | ND069116 | [2] | NUT | STA |
| 26. | ND069134 | [2] | COVER PLATE | STAMB 14 |
| 34. | ND021309 | [24] | BOLT | STAM12 x 25 |
| 35. | ND021310 | [2] | BOLT | STAM12 x 30 |
| 36. | ND021312 | [2] | BOLT | STAM12 x 40 |
| 37. | ND021324 | [19] | SCREW | STAM14 x 90 |
| 38. | ND021228 | [12] | BOLT | STAM16 x 60 |
| 39. | ND021241 | [12] | BOLT | STAM20 x 60 |
| 40. | ND021264 | [8] | BOLT | STAM24 x 90 |
| 47. | ND029268 | [19] | WASHER | STAID 14 |
| 48. | ND029269 | [12] | WASHER | STAID 17 |
| 53. | ND070130 | [2] | LUBE NIPPLE | STA |
| 54. | ND070133 | [4] | LUBE NIPPLE,M10 x 1 | STA |
| 55. | ND064758 | [6] | PLUG | STA |
| 59. | ND079313 | [4] | RING | STA90 x 98 |
