纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (12-017-00[01]) - OPERATORS COMPARTMENT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
428 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND032312 | [1] | COVER | STA |
| 2. | ND030303 | [1] | COVER | STA |
| 6. | ND051427 | [1] | WASHER | STA |
| 7. | ND098288 | [1] | EYE | STA |
| 8. | ND050686 | [2] | WASHER | STA |
| 9. | ND098289 | [2] | BOLT | STA |
| 12. | ND100028 | [1] | STRAP | STA |
| 13. | ND100029 | [1] | TAPE | STA |
| 16. | ND069779 | [2] | LOCK | STA |
| 17. | ND079506 | [4] | GROMMET | STA7 x 1 |
| 19. | ND069934 | [2] | RIVET | STAM8 |
| 20. | ND024362 | [1] | SCREW | STAM4 x 8 |
| 21. | ND026413 | [3] | NUT | STAM4 |
| 22. | ND029306 | [3] | WASHER | STAID 4,1 |
| 23. | ND029366 | [2] | COTTER PIN | STA |
| 24. | ND101964 | [12] | DECAL | STA |
