纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (12-018-00[01]) - SEAT - PIVOTING LEVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
441 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND029970 | [1] | SUPPORT | STA |
| 6. | ND057681 | [1] | COVER | STA |
| 7. | ND031641 | [1] | RETAINER | STA |
| 8. | ND029972 | [1] | PIN | STA |
| 9. | ND057688 | [16] | ROLLER | STA |
| 10. | ND069096 | [16] | BALL | STA |
| 11. | ND037249 | [1] | SPRING | STA |
| 13. | ND078866 | [1] | BALL | STA |
| 16. | ND021294 | [9] | BOLT | STAM8 x 20 |
| 17. | ND029283 | [3] | WASHER | STAID 8,4 |
| 18. | ND029310 | [9] | WASHER | STAID 8,2 |
| 20. | ND069923 | [1] | SNAP RING | STA |
