纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (04-001-00[01]) - ELECTRICAL CIRCUIT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
372 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103121 | [1] | INSTRUMENT PANEL | STA |
| 3. | ND031697 | [1] | PANEL | STA |
| 5. | ND106356 | [1] | HARNESS | STA |
| 6. | ND103164 | [1] | WIRE HARNESS | STA |
| 7. | ND103122 | [1] | WIRE HARNESS | STA Superseded by part number: ND109539 |
| 8. | ND103165 | [1] | WIRE HARNESS | STA |
| 11. | ND050584 | [1] | COVER PLATE | STA |
| 12. | ND054607 | [1] | SUPPORT | STA |
| 15. | ND067075 | [2] | WET BATTERY | STA Superseded by part number: ND111780 |
| 16. | ND067070 | [2] | TERMINAL | STA Superseded by part number: ND111732 |
| 17. | ND067071 | [2] | TERMINAL | STA Superseded by part number: ND111733 |
| 18. | ND067073 | [4] | COVER | STA Superseded by part number: ND111783 |
| 19. | ND066152 | [1] | WIRE HARNESS | STA |
| 20. | ND064972 | [1] | CIRCUIT BREAKER | STA |
| 21. | ND064523 | [1] | LAMP SOCKET | STA |
| 22. | ND064516 | [1] | SWITCH | STA |
| 23. | ND064520 | [1] | COVER PLATE | STA |
| 24. | ND065382 | [1] | SWITCH | STA |
| 25. | ND065315 | [1] | SWITCH | STAPark Brake |
| 27. | ND065401 | [1] | LENS | STA |
| 28. | ND065349 | [1] | LENS | STA |
| 29. | ND065310 | [1] | TERMINAL | STA |
| 30. | ND065309 | [2] | BEZEL | STA |
| 33. | ND064679 | [1] | HORN | STA |
| 34. | ND065735 | [1] | COVER | STA |
| 35. | ND065736 | [1] | SWITCH | STAStop Control Switch |
| 38. | ND062001 | [8] | CLAMP | STA |
| 39. | ND064849 | [1] | SLEEVE | STA |
| 40. | ND064841 | [5] | SLEEVE | STA |
| 41. | ND064822 | [5] | COVER | STA |
| 42. | ND064807 | [1] | CLAMP | STA |
| 45. | ND065786 | [1] | SWITCH | STAThrottle Sensor |
| 48. | ND090940 | [1] | MANIPULATOR | STA Superseded by part number: 84593572 |
| 52. | ND078445 | [20] | SECURING STRAP | STA |
| 53. | ND078447 | [5] | CABLE TIE | STA |
| 54. | ND066061 | [1] | TAPE | STA |
| 58. | ND024102 | [4] | BOLT | STA |
| 60. | ND023783 | [4] | BOLT | STA |
| 61. | ND024965 | [8] | SELF-TAP SCREW | STA |
| 65. | ND024121 | [6] | BOLT | STA |
| 67. | ND021287 | [1] | BOLT | STA |
| 68. | ND024137 | [6] | BOLT | STA |
| 69. | ND024234 | [16] | BOLT | STA |
| 71. | ND021295 | [1] | BOLT | STA |
| 93. | ND029311 | [1] | WASHER | STA |
| 97. | ND081766 | [1] | DECAL | STA |
| 98. | ND081909 | [1] | DECAL | STA |
| 99. | ND028174 | [1] | HYD CONNECTOR | STA |
| 100. | ND067921 | [1] | SENSOR | STA |
| 101. | ND064916 | [1] | SENSOR | STA |
