纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (09-001-01[01]) - HYDRAULIC CIRCUIT,BRAKING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
321 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | ND031247 | [1] | BLOCK | STA |
| 3. | ND105772 | [1] | SHIN | STA |
| 5. | ND067793 | [1] | BLOCK | STA |
| 8. | ND061070 | [1] | HOSE | STA |
| 9. | ND100899 | [1] | PLUG | STA |
| 10. | ND062180 | [1] | HYD CONNECTOR | STA |
| 14. | ND062217 | [2] | HYD CONNECTOR | STA |
| 19. | ND062007 | [4] | CLAMP | STA |
| 20. | ND062008 | [8] | HALF-COLLAR | STA |
| 21. | ND079932 | [2] | O-RING | STA |
| 22. | ND079933 | [4] | O-RING | STA |
| 23. | ND079934 | [2] | O-RING | STA |
| 28. | ND061389 | [1] | HOSE | STA |
| 33. | ND061915 | [1] | HOSE | STA |
| 34. | ND061917 | [1] | HOSE | STA |
| 39. | ND021295 | [8] | BOLT | STA |
| 40. | ND034059 | [16] | BOLT | STA |
| 43. | ND034062 | [4] | BOLT | STA |
| 44. | ND034064 | [4] | BOLT | STA |
