纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (10-005-00[01]) - HYDRAULIC CIRCUIT- OPERATOR'S COMPARTMENT TILTING CONTROL AND ENGINE HOOD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
508 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103127 | [1] | SERVICE KIT | STA |
| 2. | ND104300 | [1] | CYLINDER | STA |
| 3. | ND104698 | [1] | SPARE PART SET | STA |
| 4. | ND103158 | [1] | SUPPORT | STA |
| 5. | ND104738 | [1] | BRACKET | STA |
| 6. | ND104739 | [2] | BRACKET | STA |
| 7. | ND104772 | [2] | PLATE | STA |
| 10. | ND104793 | [1] | HYD. TUBE | STA |
| 11. | ND104794 | [1] | HYD. TUBE | STA |
| 15. | ND067804 | [1] | VALVE | STA |
| 16. | ND067789 | [1] | BLOCK | STA |
| 17. | ND067870 | [1] | HYDRAULIC PUMP | STA |
| 21. | ND062198 | [1] | HYD CONNECTOR | STA |
| 22. | ND062220 | [3] | HYD CONNECTOR | STA |
| 23. | ND062233 | [6] | HYD CONNECTOR | STA |
| 24. | ND062234 | [2] | HYD CONNECTOR | STA |
| 27. | ND062414 | [2] | ELBOW | STA |
| 28. | ND062313 | [1] | HYD CONNECTOR | STA |
| 30. | ND062280 | [1] | QUICK MALE COUPLING | STA Superseded by part number: ND112941 |
| 31. | ND062386 | [1] | COVER | STA |
| 32. | ND062038 | [4] | SEAL | STA |
| 33. | ND062045 | [4] | NUT | STA |
| 37. | ND061942 | [1] | HOSE | STA |
| 38. | ND061940 | [2] | HOSE | STA |
| 39. | ND061938 | [2] | HOSE | STA |
| 40. | ND061939 | [1] | HOSE | STA |
| 41. | ND061941 | [1] | HOSE | STA |
| 42. | ND061925 | [1] | HOSE | STA |
| 43. | ND061926 | [1] | HOSE | STA |
| 47. | ND064813 | [1] | CLAMP | STA |
| 48. | ND064851 | [2] | SLEEVE | STA |
| 49. | ND064807 | [2] | CLAMP | STA |
| 53. | ND024234 | [2] | BOLT | STAM6 x 30 |
| 54. | ND021179 | [3] | BOLT | STAM6 x 70 |
| 56. | ND021184 | [2] | BOLT | STAM8 x 35 |
| 57. | ND024250 | [4] | BOLT | STAM8 x 50 |
| 58. | ND021302 | [2] | BOLT | STAM10 x 25 |
| 60. | ND021311 | [4] | BOLT | STA |
| 61. | ND021216 | [8] | BOLT | STA |
| 65. | ND034086 | [8] | NUT | STA |
| 66. | ND021847 | [3] | NUT | STA |
| 69. | ND029248 | [2] | WASHER | STA |
| 70. | ND029309 | [3] | SPRING WASHER | STAID 6,1 |
| 71. | ND035940 | [4] | SPRING WASHER | STAID 8 |
| 72. | ND035941 | [2] | WASHER | STAID 10 |
| 73. | ND035942 | [12] | WASHER | STAID 12 |
