纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (10-004-00[01]) - HYDRAULIC CIRCUIT,TRAVEL - REAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
195 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | ND104748 | [1] | FITTING | STA |
| 11. | ND104799 | [1] | HYD. TUBE | STA |
| 12. | ND104800 | [1] | HYD. TUBE | STA |
| 13. | ND104801 | [1] | HYD. TUBE | STA |
| 17. | ND067795 | [1] | VALVE | STA |
| 22. | ND062153 | [3] | HYD CONNECTOR | STA |
| 27. | ND062135 | [4] | HYD CONNECTOR | STA |
| 29. | ND092607 | [1] | FITTING | STA |
| 34. | ND062262 | [2] | ELBOW | STA |
| 37. | ND062294 | [1] | HYD CONNECTOR | STA |
| 38. | ND062314 | [1] | TEE | STA |
| 50. | ND062433 | [2] | RESTRICTOR | STA |
| 63. | ND062039 | [6] | SEAL | STA Superseded by part number: 11266811 |
| 66. | ND062046 | [6] | NUT | STA Superseded by part number: 11260711 |
| 75. | ND061992 | [1] | HOSE | STA |
| 76. | ND061993 | [1] | HOSE | STA |
| 79. | ND061991 | [1] | HOSE | STA |
| 80. | ND061994 | [1] | HOSE | STA |
| 89. | ND061931 | [1] | HOSE | STA |
| 90. | ND061932 | [1] | HOSE | STA |
| 95. | ND064797 | [4] | SLEEVE | STA |
| 100. | ND064836 | [1] | SLEEVE | STA |
| 103. | ND064834 | [1] | COVER | STA |
| 106. | ND073370 | [1] | SEAL | STA |
| 111. | ND024231 | [4] | BOLT | STA |
| 118. | ND023722 | [1] | BOLT | STA Superseded by part number: ND110582 |
| 138. | ND029248 | [2] | WASHER | STA |
| 149. | ND106910 | [15] | STRAP | STA |
