| 1. |
47325
|
[1] |
CLIP
|
NH
Snap
|
| 2. |
854233
|
[1] |
KIT,60-HE, 62 Links x 19.05mm = 1181.1mm
|
NH
Roller, 60HE, 62 Pitches
|
| 4. |
86566303
|
[1] |
SPRING
|
NH
|
| 5. |
183356
|
[1] |
EYEBOLT,3/8" - 16 x 10" L
|
NH
G2, 3/8"-16 x 10-1/8"
|
| 6. |
87050048
|
[1] |
ROCKER
|
PA
Superseded by part number: 36989
|
| 7. |
87028682
|
[1] |
CHAIN (AG)
|
PA
Roller, RC50, 100 Pitches
|
| 8. |
86630851
|
[2] |
SPRING
|
NH
|
| 9. |
87040006
|
[2] |
LINK ASSY.
|
PA
|
| 10. |
86631100
|
[2] |
FLAP
|
PA
|
| 11. |
87055817
|
[1] |
SHIELD
|
PA
|
| 12. |
86610198
|
[11] |
INSERT,M6 x 1
|
NH
Threaded, M6
|
| 13. |
86626278
|
[1] |
SHIELD
|
PA
Upper, LH
|
| 14. |
87055752
|
[1] |
SHIELD
|
PA
Upper, RH
|
| 15. |
86625649
|
[1] |
SHIELD
|
PA
Lower, RH
|
| 17. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
1.8 Dual Cam Pickup
|
| 18. |
86613200
|
[1] |
IDLER,89mm OD x 47.7mm W
|
NH
Eccentric, Nylon
|
| 19. |
86626383
|
[1] |
SHIELD
|
NH
Lower, LH
|
| 21. |
495-11041
|
[1] |
WASHER,0.406" ID x 0.812" OD x 0.065" W
|
CAS
Superseded by part number: 87016
|
| 23. |
86610200
|
[4] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 24. |
705996
|
[2] |
BUSHING
|
NH
7/8" L
|
| 25. |
86632865
|
[2] |
BOLT,444.50mm
|
NH
1/2"-13 x 17-1/2" L
|
| 26. |
9706693
|
[2] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 28. |
87017232
|
[1] |
SHIELD
|
PA
|
| 29. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 30. |
844-6020
|
[20] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 31. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 32. |
614-12040
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 33. |
844-10040
|
[2] |
BOLT,Hvy Hex, M10 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 9804263, 87778247
|
| 34. |
80043480
|
[2] |
BOLT
|
PA
|
| 35. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 36. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 38. |
844-10030
|
[1] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 39. |
65319
|
[15] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 40. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 41. |
322357
|
[21] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 42. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 43. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 45. |
80664
|
[6] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 46. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 47. |
86629542
|
[4] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 48. |
825-2410
|
[1] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 50. |
425-288
|
[2] |
FLANGE NUT,Flg, 1/2"-13, G5
|
CAS
Superseded by part number: 86544265
|
| 51. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 52. |
832-46410
|
[2] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 53. |
493-21020
|
[1] |
LOCK WASHER,Int Tooth, #10
|
CAS
Superseded by part number: 280254
|
| 54. |
275-5458
|
[1] |
SELF-TAP SCREW,Hex Hd, #10 x 1/2"
|
CAS
|
| 56. |
844-8030
|
[4] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 87779272, 9804260
|
| 57. |
832-46412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 58. |
703960
|
[3] |
WASHER
|
NH
1-1/4" OD, Hardened Superseded by part number: 87642988
|
| 59. |
495-21031
|
[8] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 61. |
811-16050
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 2 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 412185
|
| 62. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
Superseded by part number: 87365
|
| 64. |
832-46416
|
[1] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 65. |
86631096
|
[2] |
SPRING NUT
|
NH
Spring
|
