| 1. |
86602143
|
[2] |
WEAR PLATE
|
NH
|
| 2. |
86624254
|
[2] |
STOP
|
NH
|
| 3. |
86602046
|
[2] |
PLATE
|
NH
|
| 4. |
86900359
|
[1] |
BRACKET
|
PA
Superseded by part number: 87656763
|
| 5. |
86602047
|
[2] |
PIVOT PLATE
|
NH
Superseded by part number: 87660305
|
| 6. |
52367
|
[1] |
HOLDER
|
NH
Shearbolt
|
| 7. |
86602446
|
[2] |
ANGLE
|
NH
|
| 8. |
86616505
|
[1] |
SPROCKET
|
NH
29T, RC80 Superseded by part number: 84244813
|
| 9. |
86978871
|
[1] |
SPROCKET
|
PA
39T, RC60, Incl 11 Superseded by part number: 87728115
|
| 10. |
234592
|
[1] |
SNAP RING,#300, Ext
|
NH
|
| 11. |
49686
|
[1] |
BUSHING,76mm ID x 82.68mm OD x 7.62mm L
|
NH
|
| 13. |
614-8020
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 14. |
16044024
|
[3] |
BOLT,Hex, M8 x 1.25 x 40mm, Cl 8.8
|
TTF
|
| 14. |
46402
|
[3] |
SHEAR BOLT
|
NH
HH, 5/16"-18 x 1-1/2" Superseded by part number: 46047
|
| 15. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 16. |
811-10025
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 86633356
|
| 17. |
811-10040
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 20. |
692300
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 7.37mm Thk
|
NH
2" OD x 3/16" Thk
|
| 21. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 24. |
832-46408
|
[3] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 25. |
825-1410
|
[6] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
