| 1. |
84350126
|
[8] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 2. |
87023410
|
[4] |
TINE BAR,300.5mm L
|
PA
|
| 3. |
54695
|
[12] |
BEARING HOUSING
|
NH
|
| 4. |
86641856
|
[12] |
BEARING,27.1 mm ID x 47 mm OD x 25.4 mm
|
PA
Superseded by part number: 54770
|
| 5. |
87642493
|
[2] |
DISC
|
NH
4-Tine Bar, Center & RH
|
| 5. |
87047356
|
[3] |
DISC
|
PA
5-Tine Bar, Optional
|
| 6. |
87643530
|
[1] |
SHAFT
|
PA
|
| 7. |
87040882
|
[4] |
ARM
|
PA
LH
|
| 8. |
134921
|
[56] |
BRACKET
|
NH
Pickup Tooth Superseded by part number: 87643386
|
| 9. |
87394242
|
[56] |
TORSION SPRING,Coiled, 2 Prong, 186.5mm L
|
NH
Pickup, Curved, Premium, Standard
|
| 9. |
87607074
|
[56] |
TINE
|
NH
Pickup, Curved, Economy, Optional
|
| 10. |
86627654
|
[56] |
SPACER
|
NH
Tooth Superseded by part number: 84427925
|
| 12. |
87642989
|
[56] |
BOLT,Tine, 5/16" - 18 x 2"
|
NH
Special, Pickup Finger
|
| 13. |
87642981
|
[1] |
DISC
|
NH
4-Tine Bar, LH
|
| 16. |
627-10030
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 9515003
|
| 17. |
434-612
|
[24] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 86508748
|
| 18. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 19. |
140020
|
[1] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 20. |
87642988
|
[16] |
WASHER,13.08mm ID x 31.8mm OD x 1.5mm Thk
|
NH
1-1/4" OD, Hardened
|
| 21. |
87642936
|
[16] |
WASHER,16.8mm ID x 27.7mm OD x 1.7mm Thk
|
NH
21/32" ID x 1-3/32" OD x .060" (16 Gauge) Thick
|
| 22. |
492-11038
|
[24] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 23. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 26. |
231-4145
|
[56] |
NUT,5/16"-18, GB
|
CAS
Superseded by part number: 280736
|
| 27. |
231-4146
|
[24] |
NUT,3/8"-16, GB
|
CAS
Superseded by part number: 88902
|
| 28. |
88130
|
[8] |
NUT,1/2"-20, GC
|
NH
|
| 29. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 31. |
136521
|
[12] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
Hardened, 1/4" x 1-3/4"
|
