凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (13.385[2]) - 1.8M DUAL CAM WIDE PICKUP, REEL, P.I.N. Y8N0388894 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
549 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84350126
|
[8] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 2. |
87732735
|
[4] |
ARM
|
PLO
LH
|
| 3. |
54695
|
[12] |
BEARING HOUSING
|
NH
|
| 4. |
86641856
|
[8] |
BEARING,27.1 mm ID x 47 mm OD x 25.4 mm
|
PA
Superseded by part number: 54770
|
| 6. |
87732304
|
[1] |
BAR
|
NH
|
| 7. |
87732736
|
[4] |
ARM
|
NH
RH
|
| 8. |
134921
|
[56] |
BRACKET
|
NH
Superseded by part number: 87643386
|
| 9. |
87394242
|
[56] |
TORSION SPRING,Coiled, 2 Prong, 186.5mm L
|
NH
|
| 10. |
84427925
|
[56] |
TOOTH
|
PLO
|
| 11. |
87056792
|
[4] |
BEARING,27.3mm ID x 47.09mm OD x 12.83mm W
|
PA
|
| 12. |
130891
|
[56] |
BOLT,Tine, 5/16" - 18 x 2"
|
NH
Superseded by part number: 87642989
|
| 16. |
9515003
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9
|
BHB
|
| 17. |
86508748
|
[24] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 3/4", Grade 5
|
BAS
|
| 18. |
86505999
|
[8] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
NH
|
| 19. |
87365
|
[16/AR] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 20. |
703960
|
[16] |
WASHER
|
NH
Superseded by part number: 87642988
|
| 21. |
26382
|
[8/AR] |
WASHER
|
NH
Superseded by part number: 87642936
|
| 22. |
80680
|
[24] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 23. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 24. |
140048
|
[8] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 26. |
86629544
|
[56] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 27. |
9637692
|
[24] |
NUT,3/8"-16, GB
|
NH
|
| 28. |
88130
|
[8] |
NUT,1/2"-20, GC
|
NH
|
| 29. |
280374
|
[8] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
|
| 31. |
136521
|
[12] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
|
