凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (13.390) - 1.8M WIDE PICKUP, REEL KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
336 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 8. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Reel
|
| 16. |
614-10030
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 17. |
811-10030
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 20. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
829-2410
|
[6] |
FLANGE NUT,M10 x 1.5, Flg, Cl 10
|
IH
Superseded by part number: 86050279
|
