| 1. |
86632865
|
[2] |
BOLT,444.50mm
|
NH
|
| 3. |
87656382
|
[2] |
SPRING
|
NH
|
| 4. |
86631989
|
[2] |
SKIRT
|
NH
|
| 5. |
235126
|
[6] |
WASHER,10.3mm ID x 38mm OD x 1.7mm Thk
|
NH
|
| 9. |
86640157
|
[2] |
SUPPORT
|
NH
|
| 11. |
87745715
|
[1] |
SHIELD
|
NH
|
| 12. |
86626278
|
[1] |
SHIELD
|
PA
|
| 13. |
86610198
|
[13] |
INSERT,M6 x 1
|
NH
|
| 15. |
86626383
|
[1] |
SHIELD
|
NH
|
| 19. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
1.8M Rotor Pickup
|
| 22. |
86625649
|
[1] |
SHIELD
|
PA
|
| 23. |
87055752
|
[1] |
SHIELD
|
PA
|
| 24. |
705996
|
[2] |
BUSHING
|
NH
|
| 25. |
86621725
|
[2] |
STRAP
|
NH
|
| 26. |
86900779
|
[2] |
SHIELD
|
PA
|
| 27. |
86629541
|
[8] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 28. |
9706687
|
[2] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 31. |
9706693
|
[2] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 33. |
9804257
|
[19] |
FLANGE BOLT,Hex, M6 x 1.0 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 34. |
9804265
|
[2] |
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
|
NH
|
| 35. |
9804261
|
[6] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 36. |
9804263
|
[2] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 37. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 39. |
80043480
|
[2] |
BOLT
|
PA
Rnd Hd Square Neck, M8.8 Course Thd
|
| 41. |
280415
|
[2] |
BOLT,Hex, 1/4" - 20 x 5", Gr 5
|
WIN
|
| 42. |
213404
|
[2] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 43. |
87020910
|
[2] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 44. |
80702
|
[14] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 45. |
9804258
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 46. |
322357
|
[20] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 47. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 49. |
140046
|
[14] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 50. |
20356
|
[2] |
NUT,1/4"-20, GB
|
PA
Superseded by part number: 280129
|
| 51. |
80701
|
[8] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 52. |
100037
|
[10] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 53. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 54. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 55. |
131405
|
[1] |
SHIM
|
NH
|
| 56. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 57. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 58. |
86521607
|
[2] |
FLANGE NUT,Flg, 1/2"-13, G5
|
NH
Superseded by part number: 86544265
|
| 61. |
86631510
|
[2] |
CHAIN,850.9mm L
|
NH
|
| 68. |
165109
|
[1] |
DECAL
|
NH
|
| 69. |
65319
|
[2] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 73. |
87026987
|
[1] |
SHIELD
|
PA
|
