| 2. |
87641160
|
[2] |
SPROCKET
|
NH
48T RC50
|
| 3. |
9849661
|
[1] |
CHAIN
|
NH
Superseded by part number: 1791DX
|
| 4. |
87641197
|
[2] |
SPROCKET
|
NH
13T RC50
|
| 5. |
86620026
|
[12] |
FLANGED BEARING
|
NH
|
| 6. |
86594423
|
[6] |
BEARING,28.6mm Hex x 72mm OD x 25mm W
|
NH
Superseded by part number: 84330069
|
| 7. |
87641813
|
[1] |
SUPPORT
|
NH
RH
|
| 8. |
87744322
|
[1] |
HEAD
|
PA
|
| 10. |
87641199
|
[1] |
ANGLE
|
NH
RH
|
| 11. |
87040398
|
[1] |
AUGER
|
PA
LH Superseded by part number: 84394191
|
| 12. |
87059146
|
[1] |
CAM
|
PA
RH Outer
|
| 13. |
87059147
|
[1] |
CAM
|
PA
RH Inner
|
| 14. |
86705250
|
[17] |
GUARD
|
PA
|
| 16. |
87641822
|
[1] |
SUPPORT
|
NH
LH
|
| 17. |
87641735
|
[1] |
CAM
|
NH
LH Outer
|
| 18. |
87641736
|
[1] |
CAM
|
NH
LH Inner
|
| 19. |
87641738
|
[1] |
ANGLE
|
NH
LH
|
| 21. |
86643381
|
[10] |
GUARD
|
NH
|
| 22. |
87040395
|
[1] |
AUGER
|
PA
RH Superseded by part number: 84394194
|
| 23. |
86626559
|
[1] |
GUARD
|
PA
End, RH
|
| 24. |
86613200
|
[2] |
IDLER,89mm OD x 47.7mm W
|
NH
|
| 25. |
86625888
|
[1] |
GUARD
|
PA
End, LH
|
| 26. |
86610199
|
[4] |
INSERT
|
PA
Superseded by part number: 84272827
|
| 27. |
9804258
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 28. |
120038
|
[6] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 29. |
9804262
|
[19] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 30. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 31. |
86512446
|
[12] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 32. |
412185
|
[2] |
CARRIAGE BOLT,Short Sq Nk, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
DUB
|
| 33. |
87039762
|
[74] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 36. |
87641641
|
[8/AR] |
WASHER,35.2mm ID x 47.75mm OD x 1.93mm Thk
|
NH
|
| 37. |
140016
|
[6/AR] |
WASHER,M8 x 16mm OD x 1.6mm Thk
|
NH
Superseded by part number: 86624184
|
| 38. |
140020
|
[2] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 39. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 40. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 41. |
140045
|
[34] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 44. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 45. |
9804278
|
[12] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 46. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 49. |
14601770
|
[2] |
LOCK PIN,M5 x 45, Slotted
|
JES
Superseded by part number: 278771
|
| 50. |
88529
|
[2] |
LOCK PIN,5.56mm OD x 44.45mm L, Slotted
|
NH
|
| 51. |
88422
|
[2] |
LOCK PIN,1/8" x 1 3/4", Slotted
|
GI
|
