| 1. |
87024365
|
[1] |
SPROCKET
|
PA
Incl 5, 6
|
| 2. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Feed Rotor
|
| 3. |
86632879
|
[2] |
CHANNEL
|
NH
Superseded by part number: 87663907
|
| 5. |
86633715
|
[1] |
SPROCKET
|
NH
31T, RC60
|
| 6. |
86629476
|
[1] |
BEARING ASSY,39mm ID x 68mm OD x 37mm W
|
NH
Includes: Seals
|
| 7. |
86625306
|
[2] |
SHAFT
|
NH
|
| 9. |
692300
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 7.37mm Thk
|
NH
2" OD x 3/16" Thk
|
| 10. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 12. |
234592
|
[1] |
SNAP RING,#300, Ext
|
NH
|
| 13. |
46402
|
[1] |
SHEAR BOLT
|
NH
HH, 5/16"-18 x 1-1/2" Superseded by part number: 46047
|
| 15. |
86616505
|
[1] |
SPROCKET
|
NH
29T, RC80 Superseded by part number: 84244813
|
| 16. |
231-4145
|
[1] |
NUT,5/16"-18, GB
|
CAS
Superseded by part number: 280736
|
| 18. |
86978871
|
[1] |
SPROCKET
|
PA
39T, RC60 Superseded by part number: 87728115
|
| 20. |
814-16100
|
[2] |
BOLT,Hex, M16 x 2 x 100mm, Cl 8.8
|
CAS
Superseded by part number: 374889
|
| 24. |
711-10030
|
[2] |
CARRIAGE BOLT,Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 25. |
811-10025
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 86633356
|
| 26. |
811-10040
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 27. |
811-8020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 31. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 32. |
140045
|
[5] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 38. |
832-46416
|
[2] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 39. |
825-2410
|
[5] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 40. |
825-1410
|
[1] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
