| 1. |
86837576
|
[1] |
SPECIAL WRENCH
|
PA
Superseded by part number: 47509866
|
| 2. |
86976003
|
[1] |
SPACER
|
PA
Superseded by part number: 87660303
|
| 3. |
9808110
|
[1] |
WASHER,46mm ID x 60mm OD x 1.64mm Thk
|
NH
Hardened, 60mm OD
|
| 4. |
86705498
|
[1] |
SPROCKET
|
PA
22T & Clutch, Standard Superseded by part number: 87660578
|
| 4. |
87045574
|
[1] |
CLUTCH
|
PA
24T & Clutch, Optional Superseded by part number: 87660580
|
| 5. |
100-11162
|
[1] |
SNAP RING,#162, Ext
|
CAS
Superseded by part number: 45440
|
| 6. |
86705492
|
[1] |
CLUTCH
|
PA
Half Superseded by part number: 87660581
|
| 7. |
196303
|
[1] |
SPRING,2.44" OD x 4.5" L
|
NH
Superseded by part number: 86640119
|
| 8. |
9829364
|
[1] |
CAP COVER
|
NH
|
| 9. |
86618213
|
[1] |
SPECIAL BOLT,M12 x 40mm, Drilled
|
NH
Cap, HH, M12 x 1.75 x 40, W/ Hole Drilled Lengthwise
|
| 10. |
86837573
|
[1] |
PLATE
|
PA
|
| 11. |
844-10025
|
[1] |
BOLT,Hex, M10 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9804261
|
| 12. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 13. |
647695
|
[1] |
PIN,7.94mm OD
|
NH
Snap
|
| 14. |
86601368
|
[1] |
BUSHING
|
NH
Superseded by part number: 86977429
|
| 15. |
87014170
|
[1] |
LATCH
|
PA
|
| 16. |
87014172
|
[1] |
STOP
|
PA
|
| 17. |
87014171
|
[1] |
ANGLE
|
PA
Superseded by part number: 87028349
|
| 18. |
86977429
|
[2] |
BUSHING,44.62mm ID x 50.93mm OD x 22.2mm L
|
PA
|
| 21. |
844-12030
|
[1] |
BOLT,Hvy Hex, M12 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9670066
|
| 23. |
844-8020
|
[2] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 24. |
844-8025
|
[1] |
BOLT,Hvy Hex, M8 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9671714
|
| 26. |
721
|
[1] |
WASHER,13.5mm ID x 22.2mm OD x 1.36mm Thk
|
NH
Spacer, 7/8" OD Superseded by part number: 86622500
|
| 27. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 33. |
825-2408
|
[2] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 34. |
832-46408
|
[1] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 35. |
832-46412
|
[1] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 38. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
Superseded by part number: 80710
|
