| 1. |
196303
|
[1] |
SPRING,2.44" OD x 4.5" L
|
NH
Superseded by part number: 86640119
|
| 2. |
9829364
|
[1] |
CAP COVER
|
NH
|
| 3. |
86618213
|
[1] |
SPECIAL BOLT,M12 x 40mm, Drilled
|
NH
|
| 4. |
80710
|
[1] |
LUBE NIPPLE,1/8” – 27 Dryseal PTF
|
DUB
|
| 5. |
9840986
|
[1] |
CLIP
|
NH
|
| 6. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 7. |
87055141
|
[1] |
SHIELD
|
PA
|
| 7. |
84211544
|
[1] |
SHIELD
|
PLO
, Start Serial: Y9N043085
|
| 8. |
84213940
|
[1] |
SHIELD
|
PLO
, Start Serial: Y9N043085
|
| 9. |
86512919
|
[1] |
LATCH
|
PA
|
| 10. |
87043305
|
[1] |
DOOR ASSY.
|
PA
|
| 11. |
87010737
|
[1] |
STRAP
|
PA
|
| 12. |
87014170
|
[1] |
LATCH
|
PA
|
| 13. |
87028349
|
[1] |
SHIELD
|
PA
|
| 14. |
87014172
|
[1] |
STOP
|
PA
|
| 15. |
86705492
|
[1] |
CLUTCH
|
PA
Superseded by part number: 87660581
|
| 16. |
45440
|
[1] |
SNAP RING,#162, Ext
|
GI
|
| 17. |
9808110
|
[3] |
WASHER,46mm ID x 60mm OD x 1.64mm Thk
|
NH
|
| 18. |
86705498
|
[1] |
SPROCKET
|
PA
Superseded by part number: 87660578
|
| 19. |
86976003
|
[1] |
SPACER
|
PA
Superseded by part number: 87660303
|
| 20. |
86837576
|
[1] |
SPECIAL WRENCH
|
PA
Superseded by part number: 47509866
|
| 21. |
87034667
|
[1] |
BRACKET
|
PA
|
| 21. |
87057528
|
[1] |
MOUNTING PARTS
|
PA
|
| 22. |
197559
|
[1] |
CHAIN,9" L
|
NH
|
| 23. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 24. |
9804255
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 25. |
9804258
|
[7] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 26. |
84821
|
[2] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| 27. |
9670066
|
[1] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 28. |
9671714
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 29. |
80684
|
[2] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 30. |
322358
|
[9] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 31. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 32. |
721
|
[1] |
WASHER,13.5mm ID x 22.2mm OD x 1.36mm Thk
|
NH
Superseded by part number: 86622500
|
| 33. |
87304
|
[2] |
NUT,#10-24
|
BEL
|
| 34. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 35. |
9804276
|
[6] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 36. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 37. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 39. |
87020910
|
[1] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
, Start Serial: Y9N043085
|
| 40. |
87013680
|
[1] |
BRACKET
|
NH
Superseded by part number: 87659758
|
| 41. |
86729275
|
[2] |
LOCK WASHER,5/8 0.634 CST ZND
|
BHB
|
| 42. |
374889
|
[1] |
BOLT,Hex, M16 x 100mm, Cl 8.8
|
NH
|
| 43. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 44. |
86837573
|
[1] |
PLATE
|
PA
|
| 45. |
9804261
|
[1] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 46. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 47. |
647695
|
[1] |
PIN,7.94mm OD
|
NH
|
