纽荷兰零件查询(CV2500) - VIBRATORY ROLLER (06-004-00[01]) - STEERING CYLINDER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
161 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND017521 | [2] | CYLINDER | STA |
| 2. | ND104719 | [1] | BRACKET | STA |
| 3. | ND104718 | [1] | BRACKET | STA |
| 7. | ND048847 | [4] | WASHER | STA |
| 8. | ND048817 | [4] | COVER PLATE | STA |
| 9. | ND048798 | [8] | RING | STA |
| 10. | ND028427 | [4] | PIN | STA |
| 11. | ND048815 | [4] | PLATE | STA |
| 15. | ND021302 | [8] | BOLT | STAM10 x 25 |
| 16. | ND021308 | [4] | BOLT | STAM12 x 20 |
| 17. | ND021243 | [10] | BOLT | STA |
| 19. | ND029311 | [4] | WASHER | STA |
| 21. | ND079782 | [8] | RING | STA |
| 25. | ND064758 | [4] | PLUG | STA |
| 29. | ND070133 | [4] | LUBE NIPPLE,M10 x 1 | STA |
