| 1. |
87023414
|
[1] |
ANGLE
|
NH
|
| 2. |
510932
|
[3] |
PULLEY,50.01mm OD
|
NH
|
| 3. |
689987
|
[3] |
ANGLE
|
NH
|
| 4. |
86629760
|
[1] |
CABLE,1772mm L
|
NH
|
| 5. |
86629062
|
[2] |
GUIDE
|
NH
|
| 6. |
86630226
|
[1] |
PLATE
|
NH
|
| 7. |
86543545
|
[4] |
GUIDE
|
NH
Cast Iron
|
| 8. |
28114
|
[4] |
U-BOLT
|
NH
#10-24 x 1-15/16"
|
| 9. |
86628978
|
[2] |
PULLEY
|
NH
Superseded by part number: 87038785
|
| 10. |
87597244
|
[1] |
ANGLE
|
NH
|
| 11. |
696365
|
[3] |
SPACER
|
NH
|
| 12. |
86509848
|
[1] |
SPRING
|
NH
Extension Superseded by part number: 217208
|
| 13. |
9612212
|
[1] |
INDICATOR
|
NH
|
| 14. |
9619090
|
[1] |
CAP COVER
|
NH
|
| 15. |
689986
|
[2] |
ANGLE
|
NH
|
| 16. |
86630225
|
[1] |
PLATE
|
NH
|
| 18. |
811-6016
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 19. |
614-8020
|
[5] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 20. |
614-8030
|
[3] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 21. |
814-10040
|
[2] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 120112
|
| 22. |
811-8020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 23. |
281020
|
[1] |
SELF-TAP SCREW,Pan HD, #8 - 18 x 3/4"
|
NH
|
| 24. |
614-10020
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 25. |
614-10030
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 26. |
86511323
|
[6] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 28. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 29. |
80684
|
[8] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 30. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 31. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 32. |
825-2410
|
[1] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 33. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 34. |
225-14110
|
[8] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 35. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 36. |
825-2408
|
[5] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 37. |
832-46408
|
[1] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
