凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (15.21) - BALE SIZE & TAILGATE LATCH INDICATOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
745 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
510932
|
[4] |
PULLEY,50.01mm OD
|
NH
|
| 3. |
696365
|
[4] |
SPACER
|
NH
|
| 4. |
704102
|
[1] |
CABLE
|
PA
Superseded by part number: 80449903
|
| 5. |
86636629
|
[1] |
SPACER
|
NH
|
| 6. |
689986
|
[4] |
ANGLE
|
NH
|
| 7. |
86632175
|
[1] |
WIRE ROPE
|
NH
|
| 8. |
9619090
|
[2] |
CAP COVER
|
NH
|
| 10. |
9612212
|
[2] |
INDICATOR
|
NH
|
| 12. |
217208
|
[1] |
SPRING
|
PA
Extension
|
| 13. |
87658510
|
[1] |
SPRING
|
NH
Extension
|
| 14. |
689987
|
[1] |
ANGLE
|
NH
|
| 17. |
140016
|
[1] |
WASHER,M8 x 16mm OD x 1.6mm Thk
|
NH
Superseded by part number: 86624184
|
| 18. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 19. |
87016
|
[1] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 20. |
9804260
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 21. |
9804258
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
322358
|
[7] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 23. |
9804277
|
[9] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 24. |
120062
|
[1] |
BOLT,Hex, M8 x 70mm, Cl 8.8
|
NH
Superseded by part number: 7120024
|
| 25. |
281020
|
[2] |
SELF-TAP SCREW,Pan HD, #8 - 18 x 3/4"
|
NH
|
| 26. |
9804276
|
[4] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 27. |
86511839
|
[2] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
WIN
|
| 29. |
43128
|
[3] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
