| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Net Actuator
|
| 2. |
86618449
|
[1] |
MOUNTING PARTS
|
NH
Superseded by part number: 87651961
|
| 3. |
86628019
|
[1] |
KNIFE ASSY
|
NH
Knife
|
| 4. |
87016776
|
[1] |
ANGLE BAR
|
PA
Superseded by part number: 87651950
|
| 5. |
87052763
|
[1] |
GUIDE
|
PA
Comb
|
| 6. |
9806864
|
[1] |
KNIFE,382mm L x 38.1mm W x 3.4mm Thk
|
NH
|
| 7. |
86593724
|
[2] |
KNIFE,445.8mm L x 38.1mm W x 3.4mm Thk
|
PA
Superseded by part number: 87013989
|
| 8. |
86619157
|
[1] |
ANGLE
|
PA
|
| 9. |
631201
|
[2] |
EYEBOLT
|
NH
3/8"-16 x 5-1/2"
|
| 10. |
87028495
|
[1] |
SPRING
|
PA
Superseded by part number: 87652453
|
| 11. |
13702
|
[1] |
SPACER
|
PA
Superseded by part number: 87652365
|
| 12. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
17/32" ID x 2" OD x 3/16" Thk
|
| 14. |
87017557
|
[4] |
FLANGE
|
PA
Bearing
|
| 15. |
66006
|
[2] |
BALL BEARING,15.88mm ID x 40mm OD x 12mm W
|
NH
|
| 16. |
183356
|
[1] |
EYEBOLT,3/8" - 16 x 10" L
|
NH
|
| 17. |
87525224
|
[1] |
MOUNTING PARTS
|
NH
LH
|
| 18. |
86622552
|
[2] |
SHIELD
|
PA
|
| 19. |
86517336
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87643130
|
| 20. |
87026847
|
[1] |
ROLLER
|
PA
Spreader, Includes: (2) Ref. 61 Superseded by part number: 87397756
|
| 21. |
87525226
|
[1] |
MOUNTING PARTS
|
NH
RH
|
| 22. |
86634792
|
[1] |
SHIM
|
NH
|
| 23. |
87010284
|
[1] |
CAMSHAFT BEARING
|
NH
Net Wrap
|
| 24. |
136443
|
[2] |
WASHER,10.32mm ID x 57.15mm OD x 4.8mm Thk
|
NH
3/8"
|
| 25. |
86631064
|
[6] |
WASHER
|
NH
|
| 26. |
748669
|
[1] |
BALL BEARING,10mm ID x 30mm OD x 9mm W
|
NH
|
| 27. |
87060186
|
[1] |
ANGLE
|
PA
|
| 28. |
86619764
|
[1] |
SPACER
|
NH
|
| 29. |
86617811
|
[1] |
PLATE
|
NH
|
| 30. |
86572215
|
[1] |
SPRING,Extension, 25.58mm OD x 240.18mm L
|
NH
Extension
|
| 31. |
86626249
|
[1] |
MOUNTING PLATE
|
NH
|
| 32. |
36803
|
[1] |
WASHER
|
PA
13/32" ID x 2" OD Superseded by part number: 87652433
|
| 33. |
419-2620
|
[2] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 281004
|
| 34. |
614-8020
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 35. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 36. |
614-6016
|
[11] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 37. |
614-10025
|
[2] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 38. |
614-12030
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 39. |
65319
|
[4] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
, Start Serial: YBN046948
|
| 40. |
413-844
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 5
|
IH
, Serial Range: -YBN046947 Superseded by part number: 87974, 87778221
|
| 40. |
87675529
|
[1] |
PIN,12.5mm OD x 69.85mm L
|
BRR
, Start Serial: YBN046948
|
| 41. |
413-836
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
, Serial Range: -YBN046947 Superseded by part number: 87975
|
| 42. |
219-17
|
[1] |
LUBE NIPPLE,3/16" NPTF
|
CAS
Superseded by part number: 80722
|
| 43. |
291525
|
[1] |
BRACKET
|
NH
Superseded by part number: 2977092, 2977092, NH291525
|
| 44. |
811-10025
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 86633356
|
| 45. |
811-10040
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 46. |
811-10070
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 70mm, Cl 8.8
|
CAS
|
| 47. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 48. |
86511323
|
[1] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 49. |
322357
|
[22] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 50. |
322358
|
[9] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 51. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 52. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 53. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
Superseded by part number: 87365
|
| 54. |
285072
|
[1] |
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
|
NH
(3/8")
|
| 55. |
825-2406
|
[8] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 56. |
825-2408
|
[6] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 57. |
825-2410
|
[6] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 58. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 59. |
231-4148
|
[2] |
NUT,1/2"-13, GB
|
CAS
, Serial Range: -YBN046947 Superseded by part number: 86992215
|
| 59. |
270964
|
[2] |
COTTER PIN,3/8" x 1.62" x .094", Int Hair
|
WIN
, Start Serial: YBN046948
|
| 60. |
232-4646
|
[1] |
LOCK NUT,3/8"-24, GC
|
CAS
Superseded by part number: 80855
|
| 61. |
27291
|
[2] |
BALL BEARING,20mm ID x 47mm OD x 14mm W
|
NH
Superseded by part number: 84330054
|
| 65. |
84293443
|
[1] |
PROTECTION PLATE
|
NH
Net Wrap, Red
|
| 65. |
84271654
|
[1] |
PROTECTION PLATE
|
NH
Net Wrap, Dk. Gray
|
| 66. |
86512439
|
[2] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 67. |
86619060
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
