| 1. |
86622528
|
[1] |
LATCH
|
NH
|
| 2. |
859896
|
[1] |
SPACER
|
NH
|
| 3. |
86601736
|
[1] |
RAMP
|
NH
Superseded by part number: 87645615
|
| 4. |
86516827
|
[1] |
HANDLE
|
NH
|
| 5. |
38668
|
[1] |
SPRING
|
NH
|
| 6. |
86627923
|
[4] |
STRIP
|
NH
Net
|
| 7. |
47473014
|
[1] |
BRAKE DRUM
|
NH
Superseded by part number: 47936342
|
| 8. |
86540330
|
[1] |
GUIDE
|
NH
|
| 9. |
87047467
|
[1] |
TUBE
|
PA
|
| 10. |
86621727
|
[1] |
ANGLE
|
NH
|
| 11. |
226829
|
[1] |
SPRING,Compression, 19.05mm OD x 77.72mm OD
|
NH
|
| 12. |
854974
|
[1] |
HANDLE
|
NH
Superseded by part number: 87475014
|
| 13. |
87035261
|
[1] |
PIVOT
|
PA
|
| 14. |
87016039
|
[1] |
CONE
|
PA
|
| 16. |
614-12035
|
[2] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 17. |
844-8020
|
[3] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 18. |
811-10030
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 19. |
614-12030
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 20. |
614-8030
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 21. |
86641297
|
[12] |
SELF-TAP SCREW,Phillips Drive, Pan HD, #8 - 18 x 3/16"
|
NH
#8 x 3/16"
|
| 22. |
814-6060
|
[1] |
BOLT,Hex, M6 x 1 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 338413, 47110227
|
| 23. |
87016189
|
[3] |
WASHER,51.18mm ID x 63.5mm OD x 1.65mm Thk
|
PA
Plated, 16 Gauge x 2.015" ID x 2-1/2" OD
|
| 25. |
86622500
|
[1] |
WASHER,13.49mm ID x 22.2mm OD x 1.36mm Thk
|
PA
Spacer
|
| 27. |
80577826
|
[1] |
WASHER,8.7mm ID x 34.93mm OD x 1.94mm Thk
|
NH
SAE, 5/16" ID x .065" Thk
|
| 29. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 30. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 31. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 33. |
825-2408
|
[4] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 34. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 36. |
832-46406
|
[1] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 37. |
832-46412
|
[2] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 38. |
86613336
|
[1] |
COTTER PIN
|
NH
|
| 39. |
86601285
|
[1] |
COTTER PIN,26mm OD x 118.5mm L
|
NH
|
| 40. |
412071
|
[1] |
LOCK PIN,8mm OD x 70mm L, Slotted
|
NH
|
| 41. |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
Superseded by part number: 80756
|
| 42. |
86617942
|
[2] |
BUSHING,48.96mm ID x 57.23mm OD x 19.1mm L
|
NH
|
