纽荷兰零件查询(CV700) - VIBRATORY ROLLER (9/01-) (12-001-00[01]) - CHASSIS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
748 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND054164 | [1] | PIN | STA |
| 2. | ND104399 | [1] | PIN | STA |
| 3. | ND030891 | [1] | COVER | STA |
| 4. | ND104397 | [2] | FLEXIBLE HOSE | STA |
| 5. | ND103151 | [1] | DOOR | STA |
| 6. | ND104291 | [1] | SUPPORT | STA |
| 7. | ND031973 | [1] | COVER | STA |
| 8. | ND103152 | [1] | DOOR | STA |
| 9. | ND104360 | [1] | SHIELD | STA |
| 10. | ND103146 | [1] | SUPPORT | STA |
| 11. | ND048918 | [1] | PIN | STA |
| 12. | ND048624 | [1] | PLATE | STA |
| 13. | ND049010 | [1] | PIN | STA Superseded by part number: ND118345 |
| 14. | ND104398 | [1] | PIN | STA |
| 15. | ND104339 | [1] | TIE-ROD | STA |
| 16. | ND030875 | [1] | COVER | STA |
| 17. | ND052503 | [3] | TIE-ROD | STA |
| 18. | ND049548 | [4] | WASHER | STA |
| 19. | ND049782 | [4] | HINGE | STA |
| 20. | ND104273 | [1] | COVER | STA |
| 21. | ND104274 | [2] | COVER | STA |
| 22. | ND031350 | [1] | PLATE | STA |
| 24. | ND104338 | [1] | PARTITION | STA |
| 25. | ND049707 | [4] | COVER PLATE | STA |
| 26. | ND018489 | [1] | COVER | STA |
| 28. | ND104412 | [1] | SHIELD | STA |
| 29. | ND104413 | [1] | SHIELD | STA |
| 30. | ND104439 | [1] | PAD | STA |
| 33. | ND051282 | [8] | WASHER | STA |
| 34. | ND104301 | [1] | PANEL | STA |
| 37. | ND090748 | [3] | STEP | STA |
| 38. | ND090769 | [1] | FILLER CAP | STA |
| 39. | ND065647 | [1] | PLUG | STA |
| 41. | ND090802 | [1] | SCREEN | STA |
| 42. | ND101956 | [1] | FLOAT | STA |
| 45. | ND024121 | [1] | BOLT | STAM5 x 12 |
| 46. | ND021289 | [4] | BOLT | STAM6 x 20 |
| 47. | ND023792 | [1] | BOLT | STAM5 x 16 Superseded by part number: ND110229 |
| 49. | ND092867 | [2] | BOLT,Hex, M8 x 14mm | STAM8 x 14 |
| 50. | ND021293 | [12] | BOLT | STAM8 x 16 |
| 51. | ND021296 | [6] | BOLT | STAM8 x 30 |
| 52. | ND021294 | [14] | BOLT | STAM8 x 20 |
| 53. | ND023825 | [4] | SCREW | STAM10 x 16 Superseded by part number: ND092562 |
| 54. | ND024702 | [28] | STUD | STAM10 x 16 |
| 55. | ND021301 | [16] | BOLT | STAM10 x 20 |
| 56. | ND021302 | [4] | BOLT | STAM10 x 25 |
| 57. | ND021295 | [2] | BOLT | STAM8 x 25 |
| 63. | ND021846 | [2] | NUT | STAM5 |
| 64. | ND026461 | [3] | NUT | STAM6 |
| 65. | ND021848 | [29] | NUT | STAM8 Superseded by part number: ND034087 |
| 66. | ND034088 | [32] | NUT | STA |
| 67. | ND021847 | [4] | NUT | STAM6 |
| 70. | ND029309 | [4] | SPRING WASHER | STAID 6.1 |
| 71. | ND029248 | [4] | WASHER | STAID 6,4 |
| 72. | ND029308 | [5] | WASHER | STAID 5,1 |
| 73. | ND029247 | [8] | WASHER | STAID 5,3 |
| 74. | ND035940 | [36] | SPRING WASHER | STAID 8 |
| 75. | ND029249 | [9] | WASHER | STAID 8,4 |
| 76. | ND035941 | [16] | WASHER | STAID 10 |
| 77. | ND029250 | [13] | WASHER | STAID 10,5 |
| 79. | ND029257 | [1] | WASHER | STA25 |
| 89. | ND079228 | [2] | BUMPER | STA |
| 90. | ND079227 | [1] | BUMPER | STA |
| 91. | ND064758 | [4] | PLUG | STA |
| 96. | ND029374 | [1] | COTTER PIN | STA |
| 97. | ND029396 | [1] | COTTER PIN | STA |
| 102. | ND101584 | [1] | TAPE | STA |
| 107. | ND073360 | [2] | PACKING RING | STA |
| 108. | ND104237 | [1] | FRAME | STA |
