凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.540.AI[01]) - VAR - 726813. 726815, 727097, 727098 - BALE TENSION HYDRAULIC CYLINDER, YFN188618 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
953 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84549525
|
[1] |
HYDRAULIC CYLINDER
|
NH
Hydraulic, Bale Tension, RH, Incl 2-9, Serial Range: -YGN193202
|
| 1. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Hydraulic, Bale Tension, RH, Incl 2-9, Start Serial: YGN193203
|
| 1. |
47624451
|
[1] |
HYDRAULIC CYLINDER
|
NH
Hydraulic, Bale Tension, LH, Incl 2-9
|
| 2. |
47624424
|
[1] |
SEAL KIT
|
NH
Incl in 1
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Rod, Incl in 2
|
| 5. |
87629
|
[1] |
NUT,5/8"-11, GB
|
GI
Nut Superseded by part number: 9602227
|
| 9. |
PL
|
[2] |
PROCURE LOCALLY
|
BAS
5/16" x 0.50" Flange Bolt
|
