凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.540.AI[02]) - VAR - 726813, 726815 - BALE TENSION HYDRAULIC CYLINDER, YFN188619 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
610 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84549526
|
[1] |
HYDRAULIC CYLINDER
|
NH
Bale Tension, Single & Dual Cylinder, RH, Incl 2-6, Serial Range: -YGN193202
|
| 1. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Tension, Single & Dual Cylinder, RH, Incl 2-6, Start Serial: YGN193203
|
| 1. |
47794184
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Tension, Dual Cylinder, LH, Incl 2-6
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Piston, Incl in 1
|
| 4. |
47631221
|
[1] |
CYLINDER HEAD
|
NH
|
| 5. |
87629
|
[1] |
NUT,5/8"-11, GB
|
GI
Superseded by part number: 9602227
|
| 6. |
47624424
|
[1] |
SEAL KIT
|
NH
|
