| 1. |
84549526
|
[1] |
HYDRAULIC CYLINDER
|
NH
Bale Density, Single Bypass, Serial Range: -YGN193202
|
| 1. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Density, Single Bypass, Start Serial: YGN193203
|
| 2. |
47482872
|
[1] |
HYDRAULIC MANIFOLD
|
NH
Incl 14 - 17, , Bale Tension, 2600 PSI without Bypass
|
| 3. |
47482859
|
[1] |
HYDRAULIC MANIFOLD
|
NH
Incl 14 - 16, 18 - 23, Bale Tension, 2600 PSI with Bypass
|
| 4. |
86505972
|
[2] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 5. |
84552131
|
[1] |
HYD TUBE
|
NH
Incl 25. 26, Serial Range: -YGN193202
|
| 5. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Hyd. Tubr, Incl 25, 26, Start Serial: YGN193203
|
| 6. |
101792A1
|
[1] |
COUPLING
|
CAS
Diagnostic
|
| 7. |
84563528
|
[1] |
HYDRAULIC HOSE,6.3mm ID x 2794mm L, SAE 100R17
|
NH
|
| 8. |
86502604
|
[1] |
DUST CAP
|
WIN
|
| 9. |
9625178
|
[1] |
PLUG,9/16" - 18 ORB
|
BEL
|
| 10. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 27
|
| 11. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 12. |
86513049
|
[1] |
PLUG,9/16" - 18 JIC
|
WIN
|
| 13. |
129274
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 14. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Manifold, Incl with 2, 3
|
| 15. |
47604142
|
[1] |
VALVE PRESSURE RELIE
|
NH
2600 PSI, Incl 18
|
| 16. |
128359
|
[2] |
O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro
|
MOD
|
| 17. |
84559455
|
[1] |
CHECK VALVE
|
NH
Incl 18
|
| 18. |
377451A1
|
[3] |
SEAL KIT
|
CAS
Needle, Incl with, 2, 3 Superseded by part number: 84556584
|
| 19. |
84558366
|
[1] |
SOLENOID VALVE
|
NH
Incl 18, 23
|
| 20. |
84300102
|
[1] |
COIL
|
BN
|
| 21. |
47358511
|
[1] |
ORIFICE
|
NH
0.094"
|
| 22. |
47358507
|
[1] |
RETAINER
|
NH
|
| 24. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
|
| 25. |
235670
|
[1] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
| 26. |
136658
|
[1] |
TUBE NUT,0.72" Length
|
BEL
|
| 27. |
9617873
|
[2] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
