凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.540.AI[05]) - VAR - 726813, 727097 - BALE DENSITY HYDRAULICS, SINGLE HYDRAUIC CYLINDER ,YGN193203 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
981 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Density, Single Bypass
|
| 2. |
47482872
|
[1] |
HYDRAULIC MANIFOLD
|
NH
Incl 14 - 17, Bale Tension, 2600 PSI without Bypass
|
| 3. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 21
|
| 4. |
86505972
|
[2] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 5. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Hyd. Tube RH, 9.5mm OD x 689.3mm Long, Incl 19, 20
|
| 6. |
101792A1
|
[1] |
COUPLING
|
CAS
Diagnostic
|
| 7. |
84563528
|
[1] |
HYDRAULIC HOSE,6.3mm ID x 2794mm L, SAE 100R17
|
NH
110" - SAE-6 9/16" 18 Female 37° JIC Straight x SAE-6 9/16" 18 Female 37° JIC 90°
|
| 8. |
86502604
|
[1] |
DUST CAP
|
WIN
Black
|
| 9. |
9625178
|
[1] |
PLUG,9/16" - 18 ORB
|
BEL
|
| 10. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 21
|
| 11. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 12. |
86513049
|
[1] |
PLUG,9/16" - 18 JIC
|
WIN
|
| 13. |
129274
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 14. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Manifold, Incl with 2, 3
|
| 15. |
47604142
|
[1] |
VALVE PRESSURE RELIE
|
NH
2600 PSI, Incl 18
|
| 16. |
128359
|
[2] |
O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro
|
MOD
|
| 17. |
84559455
|
[1] |
CHECK VALVE
|
NH
Incl 18
|
| 18. |
377451A1
|
[3] |
SEAL KIT
|
CAS
Needle Superseded by part number: 84556584
|
| 19. |
235670
|
[1] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
| 20. |
136658
|
[1] |
TUBE NUT,0.72" Length
|
BEL
|
| 21. |
9617873
|
[2] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
