纽荷兰零件查询(CV700) - VIBRATORY ROLLER (9/01-) (12-022-06[01]) - AIR CONDITIONING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
511 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND017775 | [1] | SUPPORT | STA |
| 2. | ND054272 | [1] | HYD CONNECTOR | STA |
| 4. | ND029851 | [1] | BRACKET | STA |
| 5. | ND029849 | [1] | BRACKET | STA |
| 9. | ND075571 | [1] | FOAM | STA4 x 30 x 820 |
| 10. | ND075573 | [1] | FOAM | STA4 x 105 x 200 |
| 13. | ND079515 | [1] | GROMMET | STA11 x 4 |
| 16. | ND024133 | [4] | BOLT | STAM6 x 10 |
| 17. | ND021295 | [4] | BOLT | STAM8 x 25 |
| 21. | ND021847 | [4] | NUT | STAM6 |
| 23. | ND029310 | [4] | WASHER | STAID 8,2 |
| 24. | ND029309 | [8] | SPRING WASHER | STAID 6,1 |
