| 1. |
87056843
|
[1] |
HYDRAULIC CYLINDER,38.1mm Rod, 76.2mm Stroke
|
PA
Pickup Lift Superseded by part number: 47583052
|
| 2. |
47449802
|
[1] |
CHANNEL
|
NH
Cylinder Mount
|
| 3. |
86590413
|
[1] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 4. |
86637848
|
[1] |
WASHER,13.5mm ID x 38.1mm OD x 3.68mm Thk
|
NH
|
| 5. |
86632563
|
[1] |
HEADED PIN,1" OD x 4-1/4" L, Gr 2
|
GFD
|
| 6. |
27318
|
[3] |
WASHER,26mm ID x 51mm OD x 1.5mm Thk
|
NH
|
| 7. |
80753
|
[1] |
COTTER PIN,1/4" x 1 1/2"
|
GI
|
| 8. |
9671714
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 9. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 10. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
261066
|
[1] |
ORIFICE,9/16" - 18, 0.813" Orifice
|
NH
|
| 12. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 21
|
| 13. |
86836356
|
[1] |
HOSE,9.53mm ID x 4673.6mm L, SAE 100R17
|
NH
|
| 14. |
87017806
|
[1] |
DUST CAP,Green
|
PA
Superseded by part number: 84819677
|
| 15. |
9801618
|
[1] |
QUICK MALE COUPLING,1/2" - 14
|
NH
Superseded by part number: 9412
|
| 16. |
263117
|
[4] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
|
| 17. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 18. |
9804266
|
[1] |
BOLT,Hex, M12 x 25mm, Cl 8.8, Full Thd
|
DUB
|
| 19. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 20. |
86566989
|
[1] |
CABLE TIE,208mm L
|
ZED
|
| 21. |
9617873
|
[1] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
