凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.550.AC[01]) - VAR - 727160 - TAILGATE, HYDRAULIC LIFT, STANDARD EJECT, YFN188619 AND AFTER Case Agriculture_凯斯Case_工程机械

凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (35.550.AC[01]) - VAR - 727160 - TAILGATE, HYDRAULIC LIFT, STANDARD EJECT, YFN188619 AND AFTER Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 414 次

Pos.	Part No	Qty	Parts name	Comments
1.	84606149	[1]	VALVE WITH LEVER	NH Incl 38, 38
2.	86512938	[4]	90 ELBOW,90 Degree, 37 Degree 3/4"-16 x 9/16"-18 ORB	NH Incl 39
3.	81827427	[1]	HYD CONNECTOR,3/4" - 16 JIC x 3/4" - 16 ORB	A Incl 40 Superseded by part number: 86301S36
4.	47860631	[1]	HYD TUBE	NH 9mm ID x 12mm OD, SAE J525, Incl 35, 36
5.	47860625	[1]	HYD TUBE	NH .37"ID x .50" OD, SAE J525, Incl 35, 36
6.	259619	[1]	HYD CONNECTOR,3/4" - 16 ORB x 3/4" - 16 ORB	WIN Incl 40 Superseded by part number: 87412765
7.	47736727	[1]	HYDRAULIC HOSE,10mm ID x 1270mm L, SAE 100R17	NH
8.	47736820	[1]	HYDRAULIC HOSE,10mm ID x 2840mm L, SAE 100R17	NH Superseded by part number: 47862226
9.	87517395	[2]	HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 373.38mm Stroke	PA Tailgate Lift, Standard Eject
10.	47860613	[1]	HYD TUBE	NH .37"ID x .50" OD, SAE J525, Incl 35, 36
11.	47843875	[1]	HYD CONNECTOR,3/4" - 16 x 3/4" - 16	NH
12.	84416929	[1]	PLATE	PLO
13.	120056	[5]	BOLT,M6 x 1.0 x 54.15mm, Cl 8.8	NH
14.	47733861	[2]	HYDRAULIC HOSE,10mm ID x 3690mm L, SAE 100R17	NH
15.	47721222	[1]	HYDRAULIC HOSE,10mm ID x 650mm L, SAE 100R17	NH
16.	128996	[1]	TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC	WIN
17.	47862228	[1]	HYDRAULIC HOSE,10mm ID x 3937mm L, SAE 100R17	NH
18.	353308	[5]	NUT,M6 x 1.0, Cl 8	NH
19.	87301276	[2]	HYD CONNECTOR,45 Degree, 9/16" - 18 ORB x 3/4" - 16 JIC	WIC Incl 39
20.	431941	[3]	SUPPORT	DUB
21.	47576842	[1]	HANDLE GRIP	NH
22.	84407295	[5]	BASE	BN
23.	9671714	[3]	FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8	NH
24.	9804277	[2]	FLANGE NUT,Hex, M8 x 1.25, Cl 8	NH Superseded by part number: 86505868
25.	86610200	[3]	THREADED INSERT,M8 x 1.25	NH
26.	9801618	[2]	QUICK MALE COUPLING,1/2" - 14	NH Superseded by part number: 9412
27.	86621124	[2]	DUST CAP	NH Black
28.	87034173	[21]	CABLE TIE,774.7mm L	PA Superseded by part number: 529070
29.	86511842	[2]	BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8	NH
30.	430357	[6]	CLAMP	DUB
31.	87399	[1]	COTTER PIN,1/2 x 3 Bolt	GI
32.	87367	[2]	WASHER,1.06" ID x 2" OD x 0.13" Thk	PA
33.	86517438	[1]	ORIFICE	NH
34.	26402	[2]	WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk	NH
35.	129428	[1]	TUBE NUT,37 Degree, 3/4"-16, Type B	GI
36.	235671	[1]	SLEEVE,37 Degree, 1/2" Tube	DUB
37.	47382486	[1]	VALVE LEVER	NH
38.	47382510	[1]	SEAL KIT	NH
39.	9617873	[1]	O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro	NH
40.	128825	[1]	O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro	NH
